Part Number: FT-CTS-AC
Armored Cable Ceramic Temperature Sensor 1510nm-1590nm -10~80℃ 3.0mm
Ceramic Temperature Sensor packaging is made from a ceramic material, the use of temperature-sensitive grating own features to monitor the temperature. It can be packaged into without any weld point temperature sensor string, bring convenience for the application.
Key Features
- Mini-Size
- Fast response
- High stability and reliability
- Immune to electrics
- Single Sensor Technical
Application
- For power plants, railways and oil fields long testing.
Specification
| Parameter | Minimum value Maximum value | |
| Wavelength range(nm) | 1510 | 1590 |
| -3dB broadband (nm) | 0.25 | / |
| Temperature resolution (℃) | 0.05 | |
| Temperature accuracy(℃) | 0.5 | 1 |
| Temperature range(℃) | -10 | 80 |
| Insertion loss(IL) (dB) | 0.5 | / |
| Dimension(mm) | 40*4*4 | |
| Pigtail(mm) | Φ 3 indoor cable or armored cable | |
| Connector type | Customized |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
