Part Number: FT-D2030
Desktop Variable Optical Attenuator FT-D2030(0～60dB)
Desktop Variable Optical Attenuator FT-D2030(0～60dB) is based on MEMS technology. It has high definition, high response speed, good linearity,high resolution and low IL, and especially it has calibration function,so it is an ideal instrument for optical network system and optical engineering test.
Key Features
- MEMS design , high accurency
- high reliability, Follow Telcordia
- Low insertion Loss , high Return Loss
- Automatic calibration, output display
Specification
| Working wavelength(nm) | 1310/1490/1550 |
| Attenuation Range (dB) | 0～60 |
| Excess Loss (dB) | -2 |
| Attenuation accuracy (dB) | 0.05 |
| Attenuation Step(dB) | 0.01 |
| Optical Monitor Range(dBm) | -65 ～ +10 |
| Test Uncertainty (dB) | ±0.13 (3%) |
| Test Linear (dB) | 0.02 |
| Display resolution(dB) | 0.01 |
| Communication | RS232/GPIB |
| Control interface | 5V 3A |
| Working temperature (℃) | -10~+40 |
| Storage temperature (℃) | -25~+70 |
| Weight (kg) | 3k |
| Dimension(mm) | 385*260*120 |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
