Part Number: FT-D3030
Desktop Variable Optical Attenuator FT-D3030(0～60dB)
Desktop Variable Optical Attenuator FT-D3030(0～60dB) is based on MEMS VOA technology. It has high definition, high response speed, good linearity,high resolution and low IL, and especially it has calibration function,so it is an ideal instrument for optical network system and optical engineering test.
Key Features
- Low IL
- Wide attenuation range
- High responsivity
- High resolution
- Remarkable reliability
Applications
- System sideband analysis
- System loss simulation
- Optical power calibration and verification
- Scientific laboratory equipment
Specification
| Attenuation Range(dB) | 0dB～60dB |
|---|---|
| Resolution(dB) | ≤±0.1 |
| Accuracy@0~30dB | ≤±0.3 |
| Accuracy@0~60dB | ≤±0.6 |
| Repeatability(dB) | ≤±0.2 |
| Stability（dB） | ≤±0.2 |
| InsertionLoss(dB) | ≤2.0（1550nm/1310nm） |
| Calibration(nm) | 1550/1310 |
| ReturnLoss(dB) | ≥45 |
| InputPower(mW) | ≤500 |
| FiberType | SMF-28 |
| ConnectorType | FC/UPCorFC/APC |
| SupplyPower | AC:100-240V50/60Hz |
| CommnicationInterface | RS232 |
| PowerConsumption（mW） | <200 |
| OperatingTemperature（℃） | –5～50 |
| StorageTemperature（℃） | –25～70 |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
