Part Number: FT-E037U
EPON ONU with 1-PON Port and 24 10/100M ports
FT-E037U series is F-tone company access to applications for large-scale carrier-grade EPON FTTB ONU equipment, the series follows the IEEE 802.3-2005 comprehensive EPON equipment and technical requirementss of China Telecom V2.1, unified, open software and hardware architecture provide a powerful network management capabilities, to achieve a flexible network and management system, with telecom-grade operations, manageability and easy to maintain. Provide users with fiber to the building (FTTB, Fiber To The Building) solutions.
Product features:
Conform to IEEE802.3ah standard and meet CTC V2.1 technical requirements
Support Ethernet service layer 2 switching and wire-speed forwarding of uplink and downlink services
Support frame filtering and suppression
Support standard 802.1Q Vlan function, support VLAN conversion
Support 4094 VLANs (802.1Q)
Support Dynamic Bandwidth Allocation (DBA) function
Support QoS, including traffic flow classification, priority marking, queue and dispatch, traffic shaping and traffic control, etc
Single ONU supports up to 8 LLID.
Support IGMP Snooping
Support Ethernet port ratelimit loop detection
Support power failure alarm
Support lightning protection for power supply and lightning protection for service port
Port features:
1 PON ports (1.25G)
24 10/100M port
Physical features:
Physical dimension: 440*207*43.6 (L×W×H, unit: mm)
Power supply:100-240VAC
Power consumption: 22W
Temperature:
Working temperature: -10℃~+55℃;
Storage temperature: -30℃~+60℃;
Relative humidity: 10℃~+90℃ (non-condensing)
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
