Part Number: FT-FAST-LC-SM-6
AFL FastConnect - LC/UPC Singlemode 900um FAST-LC-SM-6
FASTConnect® field-installable connectors are factory pre-polished connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub and a proprietary index-matching gel combine to offer an immediate low loss termination to either single-mode or multimode optical fibers.
FASTConnect® connectors are compatible with 250 µm and 900 µm optical fibers, as well as 900 µm, 2 mm and 3 mm cordage. All primary fiber types are supported, and each connector is color coded per industry-standard requirements to aide in identification during and after installation. A factory-installed wedge clip (included with each connector) is removed and discarded upon completion of the termination. Incorporated into this device is an innovative, translucent wedge enabling the use of a common VFI to provide a “pass/fail” signal once physical contact is achieved.
Features
● Pre-stubbed, factory-polished ferrule
● No epoxy required
● Precision mechanical alignment ensures low loss
● Fiber can be reseated
● 900uum boot provided with each connector with separate boot kits available for 2.0 and 3.0mm diameter style cables
● VFI can be used to confirm fiber is installed properly
Applications
● Premise environments
● Connections at the desk for LAN environments
● Patch panels
● Direct equipment termination
● Fiber to the Subscriber (FTTx) applications
● Repair and replacement requirements
● Equipment test leads
Specifications
| Parameter | Value |
| Fiber Type | Singlemode and Multimode |
| Insertion Loss (Max) | SM APC 0.6dB, SM UPC 0.5dB, MM 0.5dB |
| Insertion Loss (Typical) | SM APC 0.3dB, SM UPC 0.2dB, MM 0.1dB |
| Return Loss (Typical) | SM APC ≤-55dB, UPC ≤-50dB, MM ≤-25dB |
| Polishing Type | PC, UPC and APC |
| Operating Temperature | -40°C to +75°C |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
