Part Number: FT-FBG
FM SKU#:SKU00182G2
Model#:FT-FBG
MFG PART#:
Pressure FBG Sensor
The pressure sensor is designed to measure fluid pressure or levels. There is double FBG inside the stainless steel housing. One FBG is used to measure the pressure. Simultaneously, as temperature compensation, another FBG is used to monitor the temperature. The sensor can be equipped with a special kit of thread which can connect with different interfaces.
Key Features
- Range: 1Mpa, 2Mpa, 3Mpa, 5Mpa, 7Mpa
- Long-term reliability
- High accuracy and resolution
- Large measurement range
- Excellent waterproofing properties
- Simultaneous measurement of temperature and pressure
Application
- One FBG is used to measure the pressure. Simultaneously, as temperature compensation, another FBG is used to monitor the temperature.
Specification
| Parameter | Unit | Minimum value | Typical value | Maximum value |
|---|---|---|---|---|
| Center Wavelength | nm | 1510 | / | 1590 |
| Pressure Measurement Range | MPa | 1 | Customized | 10 |
| Pressure Accuracy | / | 0.50% | / | |
| Temperature Resolution | ℃ | 0.05 | 0.1 | 0.1 |
| Temperature Accuracy | ℃ | 0.5 | 1 | 1 |
| Temperature Range | ℃ | -20 | / | 80 |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
