Part Number: FT-FDB-16
FDB-16 Fiber Splitter Distribution Box
FTT-FDB16 Type Optical Termination Box is designed to connect feeder/distribution cable to subscriber's drop cable using PLC splitter in FTTx networks. It has 2 input ports and 16 output ports on the bottom and it is easy to install on the wall or pole. The rear tray is for splicing a fiber of feeder cable with PLC splitter and the front tray is for connecting subscriber's drop cable through adaptor plate on the tray.
Note: This box does not come with any adapters, pigtails and fiber splitters. If you need them, we can install them for you with few charges.
Features
- User familiar industry interface, using high impact plastic PC/ABS
- Can accommodate 1x16 bare fiber PLC splitter
- Can put out 16 fiber cable
- Ultra violet resistant and rainfall resistant
- Up to 16 FTTH drops
- Wall and pole mountable
- 2 inlet ports, 16 outlet ports
- Dimensions: 320*260*90mm
Applications
- Widely used in FTTH access network.
- Telecommunication Networks
- CATV Networks
- Data Communications Networks
- Local Area Networks
Specifications
| ITEM | Data sheet | |
|---|---|---|
| Dimensions | L : 320mm, W: 260mm, H : 90mm | |
| Weight | 3kg | |
| Cable input port | Max. 2 ports (Max. dia. : 12mm) | |
| Cable output capacity | Max. 16 ports (Max. dia. : 3mm) | |
| Max. Capacity | 16 core | |
| Operation Temperature | -40 ~ +85 ℃ | |
| Other parameter | Tensile strength | ≥ 450 kg/cm2 , @10mm/min |
| Impact Strength | 35 kgcm/cm2 (normal temp.), 10 kgcm/cm2 (-30℃ ) | |
| Flexural strength | ≥ 450 kg/cm2 , @10mm/min |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
