1U Height 12 Slots Mini Media Converter Rack Mount Chassis with Dual Power AC 220V

Part Number: FT-MFMC-12Slot-AC

1U Height 12 Slots Mini Media Converter Rack Mount Chassis with Dual Power AC 220V

The Chassis-based Media Converters include a number of independent media converters and a chassis capable of housing up to 14 media converters. You can start with single media converters, each equipped with its own housing and AC power adapter. When your requirements grow big, you can mount a chassis in your equipment rack and install your media converters in the chassis. The housing of each media converter can be easily removed, and the media converter PC board can be slid into the chassis.

The chassis lets you install multiple media converters in an equipment rack together with the network devices for which they provide media conversion. This provides for space saving, and the cabling will look neat. The chassis comes with its own universal AC to DC power supply. For maximum power availability, an optional redundant power supply is available for installation in chassis.

F-tone.COM supply two types of rack-mounted chassis for unmanaged media converters: 2U 14 slots media converter chassis and 2U 16 slots media converter chassis. The 14 slots media converter chassis supports plug-and-play installation of stand-alone media converters convert modules. It can hold at most 14 pieces media converters. The 16 slots media converter chassis should be used with card-type media converters.It can hold at most 16 card-type converters of 10/100M.

Note：The Rack Chassis is empty, no Media Converter is included.

Key Features

• Suitable for standard 19 inch network rack
• 1U height, maximum 12 slots capacity
• Supports several module type media converters
• Supports redundant power supply modules
• Supports hot-swappable operating
• Two side LED indicators (front and rear)
• The 1U height 12 slots media converter rack mount chassis is specially designed for accommodating chassis-based mini Media Converters. It is a standard 19 inch 1U height rack mount chassis which can be mounted in the standard 19-inch rack. The chassis lets you install multiple mini media converters in an equipment rack together with the network devices. This provides for space saving, and the cabling will look neat. The chassis works with its own universal AC/DC or DC/DC power supply. For maximum power availability, an optional redundant power supply is available for installation in the chassis. The configuration of active/standby power supply ensures uninterruptible operation of the system

Technical Specifications

Ordering Information

• FT-R12AA (12-slot dual AC/DC power suppliers)
• FT-R12AD (12-slot combined AC/DC and DC/DC power suppliers)
• FT-R12DD (12-slot dual DC/DC power suppliers)

Label Customized

Note: Neutral or customized label are available per your requirements.please feel free to contact us at [email protected] for more details.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
