Part Number: FT-S5630-X
Layer3 S5630 Series Managed Ethernet Switch
S5630 Series are layer 3 managed fiber switches, supports up to 48 * SFP ports and 4 10G SFP+ uplink ports, which owns complete layer 2 functions such as QoS, VLAN, IGMP Snooping/GMRP, Port Trunking, SNMP V1/V2/V3, RSTP/STP/ERPS, etc. It also supports layer 3 functions such as static routing, RIP V1/V2, OSPF, VRRP, etc. protocol. It has AC+DC power supply for option, and wide temperature design, strong anti-electromagnetic interference capability, it’s a good solution for enterprise or telecom networks.
Features
● 24*1G Combo / 48*1G Base-X SFP port
● 4*10G SFP+ uplink port
● 128/176Gbps switching capacity
● Optional AC+DC power supply
● Layer3 static & dynamic routing
Application Solution
Specifications
| Attribute | S5630-24TS4SX | S5630-48SF4SX |
|---|---|---|
| Port | 24*1000M/1G Combo; 4*1000M Base-X SFP/10GE SFP+ | 48*1000M/1G Base-X SFP; 4*1000M Base-X SFP/10GE SFP+ |
| Chipset | Marvell 98DX3510Marvell 98DX3510 | |
| Switching Capacity | 128Gbps | 176Gbps |
| Forwarding Rate | 95.24Mpps | 130.95Mpps |
| MAC Address | 32K | |
| Multicast Address | 4K | |
| Route | 12K | |
| RAM & Flash | 1GB / 8GB | 4GB / 16GB |
| Power Supply | AC: 100～240V; 47/63Hz DC: -20V ~ -60V |
Fixed AC: 100～240V, 47/63Hz |
| Power Consumption | ≤63W | ≤80W |
| Dimension (L*W*H) | 440*368*44mm | 440*330*44mm |
| Environment Temperature |
Working Temperature: -10℃~ 50℃ Storage Temperature: -40℃~ 70℃ Relative Humidity: 5%~95%, non-condensing |
|
| Software Features | ||
| VLAN | MAC and protocol VLAN, static QinQ and Flexible QinQ | |
| Ring Protocol | STP/RSTP/MSTP, ERPS | |
| Port Control | Support | |
| Port Aggregation | Static link aggregation Support dynamic LACP | |
| Mirroring | Support | |
| ACL | Support standard and extended ACL | |
| QoS | COS/DSCP priority, Flow mirror | |
| Safety | IEEE 802.1X authentication, Radius &TACACS+ authentication | |
| Layer3 Routing | Static/dynamic routing, RIP/OSPF/BGP/IS-IS | |
| Management | CLI、Telnet、WEB、SNMP V1/V2/V3、SSH | |
Product Features
| Stability | QoS Capabilities |
|---|---|
| ● Linux operating system ● IPv4/IPv6 dual protocol stack platform ● STP/RSTP/MSTP/ERPS/LACP etc. |
● Support port speed and flow speed limit ● Support Service flow and QoS flow control ● Support SP/WRR/SP+WRR ● Support port-based and service flow-basedmirroring functions |
| Safety Mechanism | Routing Protocol |
| ● Support ACL security filtering mechanism based on MAC, IP, L4 port ● Support Anti-ARP & User Blocking function ● Support DHCP attack automatic protection ● Support DDOS and virus attack protection ● Support DHCP/IP/802.1X etc. ● Support BFD, FlexLink, LACP and ERRP etc. ● Support Remote Loop Detection function ● Support CFM、EFM ● Support Tacacs+, Radius, and Local user authentication |
● Support Static Route ● Support RIP, OSPF,BGP, ISIS ● Support IPV4/IPV6 dual protocol stack ● Support RIPng、OSPFv3 |
| Multi-service Capabilities | Network Management |
| ● Support DHCP Server and DHCP Relay ● Support L2-Tunnel ● Support Ethernet OAM protocol (CFM、EFM) |
● Support CLI based on RS232 serial port, Telnet and SSHv2 ● Support RFC1213 SNMP ● Support WEB-based configure operation ● Support SNMP V1/V2/V3 ● Support FTP & TFTP remote upgrade and download |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
