Part Number: FT-S5700-X
Layer2 S5700 Series Managed Ethernet Switch
The S5700 series switch is a layer 2 Ethernet switch, which meets the needs of cost-effective Gigabit access and Gigabit uplink for enterprise networks and operator customers. This series uses a high-performance low-power network processor, provides Gigabit line-speed forwarding performance, supports green Ethernet line sleep capability, has the lowest power consumption of the same-level equipment in the industry,
Features
● 10/100/1000M Ethernet port
● 1000M Base-X SFP uplink port
● 20Gbps/56Gbps switching capacity
● 32M/256M flash/RAM
● IEEE 802.3af/at （PoE type）
● Layer2 full management
● Single Power Supply
Application Solution
Specifications
| Attribute | S5700-8T2S | S5700-8TP2S | S5700-24T4S | S5700-24TP4S |
|---|---|---|---|---|
| Interface | 8*10/100/1000M Base-T | 8*10/100/1000M Base-T /PoE | 24*10/100/1000M Base-T | 24*10/100/1000M Base-T /PoE |
| Uplink Port | 2*1000M Base-X SFP | 4*1000M Base-X SFP | 4*1000M Combo | |
| Chipset | Realtek 8380M Series | RTL8382M / RTL8218D | ||
| Switching | 20Gbps | 56Gbps | ||
| Forwarding Rate | 14.88Mpps | 41.664Mpps | ||
| PoE Standard | / | IEEE 802.3.af/at | / | IEEE 802.3.af/at |
| PoE Budget | / | 135W | / | 400W |
| MAC Address | 8K | |||
| RAM & Flash | RAM: 256MB; Flash: 32MB | |||
| Power Supply | AC: 100～240V 47/63Hz | |||
| Power Consumption | Idle≤10W Full load≤18W |
Idle≤10W Full load≤18W |
≤24W | ≤450W |
| Dimension (L*W*H) | 200X149X44mm | 440X209X44mm | ||
| Environment Temperature |
Working Temperature: -10℃~ 50℃ Storage Temperature: : -40℃~ 70℃ Relative Humidity: 5%~95%, non-condensing |
|||
| Software Features | ||||
| VLAN | MAC and protocol VLAN, QinQ and fiexible QinQ | |||
| Spanning Tree | STP/RSTP/MSTP | |||
| Port Control | Suppor | |||
| Port Aggregation | Static link aggregation Support dynamic LACP | |||
| Mirroring | Support | |||
| ACL | Support standard and extended ACL | |||
| QoS | 802.1P, DSCP priority | |||
| Safety | IEEE 802.1X authentication, Radius&TACACS+ authentication | |||
| L2 Ring protection | MRPP、ERPS(G.8032)、Loopback Detection、Fast Link | |||
| Management | CLI、Telnet、WEB、SNMP V1/V2/V3、SSH | |||
Product Features
| Stability | QoS Capabilities |
|---|---|
| ● Linux operating system ● IPv4/IPv6 dual protocol stack platform ● STP/RSTP/MSTP/ERPS/LACP etc. |
● Support port speed and flow speed limit ● Support Service flow and QoS flow control ● Support SP/WRR/SP+WRR ● Support port-based and service flow-basedmirroring functions |
| Safety Mechanism | Routing Protocol |
| ● Support ACL security filtering mechanism based on MAC, IP, L4 port ● Support Anti-ARP & User Blocking function ● Support DHCP attack automatic protection ● Support DDOS and virus attack protection ● Support DHCP/IP/802.1X etc. ● Support BFD, FlexLink, LACP and ERRP etc. ● Support Remote Loop Detection function ● Support CFM、EFM ● Support Tacacs+, Radius, and Local user authentication |
● Support Static Route ● Support RIP, OSPF,BGP, ISIS ● Support IPV4/IPV6 dual protocol stack ● Support RIPng、OSPFv3 |
| Multi-service Capabilities | Network Management |
| ● Support DHCP Server and DHCP Relay ● Support L2-Tunnel ● Support Ethernet OAM protocol (CFM、EFM) |
● Support CLI based on RS232 serial port, Telnet and SSHv2 ● Support RFC1213 SNMP ● Support WEB-based configure operation ● Support SNMP V1/V2/V3 ● Support FTP & TFTP remote upgrade and download |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
