Part Number: FT-S5710-X
Layer3 S5710 Series Managed Ethernet Switch
S5710 has series of fully Gigabit Layer 3 managed stackable Ethernet switches, support up to 8/24/48 Gigabit ports and 10G SFP+ uplink ports, which own complete layer 2 functions such as QoS, VLAN, IGMP Snooping/GMRP, Port Trunking, SNMP V1/V2/V3, RSTP/STP/ERPS, etc. It also supports layer 3 functions such as static routing, RIP V1/V2, OSPF, VRRP, etc. protocol. Optional AC+DC dual power supply, has wide temperature design, strong anti-electromagnetic, and interference capability, This switch is a good solution for enterprise or telecom networks.
Features
● 10/100/1000M Ethernet port
● 10G SFP+ uplink port
● 96Gbps/216Gbps switching capacity
● 802.3az energy saving
● Single power supply
● Layer3 static & dynamic routing
● Support stacking function
Application Solution
Specifications
| Attribute | S5710-12TX | S5710-28TX | S5710-28SX | S5710-48T4SX | S5710-54TX |
|---|---|---|---|---|---|
| Interface | 8*10/100/1000M Base-T | 24*10/100/1000M Base-T | 20*1G SFP 4*10/100/1000M Combo | 48*10/100/1000M Base-T | 48*10/100/1000M Base-T |
| Uplink Port | 4*10G SFP+ | 4*10G SFP+ | 4*10G SFP+ | 4*10G SFP+ | 6*10G SFP+ |
| Chipset | RTL9301 Series | RTL9311 series | |||
| Switching | 96Gbps | 128Gbps | 176Gbps | 216Gbps | |
| Forwarding Rate | 71.43Mpps | 95.24Mpps | 130.944Mpps | 160.71Mpps | |
| MAC Address | 16K | 32K | |||
| RAM & Flash | RAM: 512MB; Flash: 32MB | ||||
| Power Supply | AC: 100～240V; 50/60Hz；DC: 47V～63V | ||||
| Power Consumption | Idle≤10W Full load≤20W |
Idle≤13W Full load≤30W |
Idle≤13W Full load≤58W |
Idle≤30W Full load≤60W |
Idle≤25W Full load≤53W |
| Dimension (L*W*H) | 270*180*44mm | 440*210*44mm | 440*210*44mm | 440*260*44mm | 440*290*44mm |
| Environment Temperature |
Working Temperature: -10℃~ 50℃ Storage Temperature: -40℃~ 70℃ Relative Humidity: 5%~95%, non-condensing |
||||
| Software Features | |||||
| VLAN | MAC and protocol VLAN, QinQ and fiexible QinQ | ||||
| Ring Protocol | STP/RSTP/MSTP, ERPS | ||||
| Port Control | Suppor | ||||
| Port Aggregation | Static link aggregation Support dynamic LACP | ||||
| Mirroring | Support | ||||
| ACL | Support standard and extended ACL | ||||
| QoS | 802.1P, DSCP priority | ||||
| Safety | IEEE 802.1X authentication, Radius & TACACS+ authentication | ||||
| Layer3 Routing | Static/dynamic routing, RIP/OSPF/BGP/IS-IS | ||||
| Management | CLI,Telnet,WEB,SNMP V1/V2/V3、SSH | ||||
Product Features
| Stability | QoS Capabilities |
|---|---|
| ● Linux operating system ● IPv4/IPv6 dual protocol stack platform ● STP/RSTP/MSTP/ERPS/LACP etc. |
● Support port speed and flow speed limit ● Support Service flow and QoS flow control ● Support SP/WRR/SP+WRR ● Support port-based and service flow-basedmirroring functions |
| Safety Mechanism | Routing Protocol |
| ● Support ACL security filtering mechanism based on MAC, IP, L4 port ● Support Anti-ARP & User Blocking function ● Support DHCP attack automatic protection ● Support DDOS and virus attack protection ● Support DHCP/IP/802.1X etc. ● Support BFD, FlexLink, LACP and ERRP etc. ● Support Remote Loop Detection function ● Support CFM、EFM ● Support Tacacs+, Radius, and Local user authentication |
● Support Static Route ● Support RIP, OSPF,BGP, ISIS ● Support IPV4/IPV6 dual protocol stack ● Support RIPng、OSPFv3 |
| Multi-service Capabilities | Network Management |
| ● Support DHCP Server and DHCP Relay ● Support L2-Tunnel ● Support Ethernet OAM protocol (CFM、EFM) |
● Support CLI based on RS232 serial port, Telnet and SSHv2 ● Support RFC1213 SNMP ● Support WEB-based configure operation ● Support SNMP V1/V2/V3 ● Support FTP & TFTP remote upgrade and download |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
