Part Number: FT-S6670-48XY8QC
S6670 Series Layer3 Managed Ethernet Switch
The S6670-48XY8QC is a high-performance Layer 3 switch designed for enterprise, data center, and carrier networks. It features 48 10/25G SFP28 ports and 8 40/100G OSFP28 uplinks, supporting wire-speed forwarding for low latency and high-bandwidth performance. With Layer 2/3 functionalities, VLAN, ACL, and Q-in-Q, it enables efficient traffic management and enhanced security. Equipped with dual FRU redundant power supplies and hot-swapping, it ensures high availability for mission-critical environments. Its resilient stacking capability simplifies management and supports scalability by combining multiple units into a single logical device. Ideal for data centers, enterprise campuses, or service provider networks, the S6670-48XY8QC delivers exceptional performance and flexibility, meeting evolving network demands.
Product Highlights
● 48*1G/10G/25G SFP28; 8*40G/100G QSFP28
● 1* Console RJ45; 2*100/1000M RJ45 MGMT, 1*USB
● 4Tbps Switching capacity
● Support Dual-FRU AC or DC redundant power supply
● AC: 100～240V 47/63Hz
● DC: -40V ~-60V.
● Support stacking function
Application Solution
Feature
| Attribute | S6670-48XY8QC |
|---|---|
| QSFP28 Port | 48*1000/10G/25G Base-X SFP28, 8*40G/100G Base-X QSFP28 |
| Switching Capacity | 4Tbps |
| Forwarding Rate | 2800Mpps |
| MAC Address | 128K |
| Packet Buffer | 192Mbit |
| RAM/Flash | RAM: 4GB; Flash: 8GB |
| Packet Buffer | 192Mbit |
| Power Supply | AC: 100～240V, 47~63Hz; DC: -40V~ -60V |
| Power Consumption | ≤500W |
| Dimension (L*W*H) | 440*410*44mm |
| Environment Temperature | Working Temperature: -10℃～50℃ Storge Temperature: -40℃～70℃ Relative Humidity: 5%~95%, non-condensing |
Specification
| Software Feature | |
|---|---|
| VLAN | Support 4K VLANs; Support 1: 1 and N: 1 VLAN switching; Support basic and flexible QinQ |
| MAC | Support 128K MAC address table; Support Port MAC address filtering; Support blackhole MAC |
| Stackable | Support Sacking of 8 units through a single IP address; Support Unified management. Support Redundancy mechanism; Support High speed interconnect |
| Port | Support bidirectional bandwidth control; Support static and dynamic LACP aggregation Support multi-port mirroring; Support port storm suppression Support 9K Jumbo ultra-long frame forwarding |
| ACL | Support standard and extended ACL; Support ACL policy based on time period |
| QoS | Supports port-based traffic policing and the two-speed, three-color CAR function |
| Multicast | Support Layer 2 multicast entry 8K; Support IGMPv1 / v2 / v3 Snooping; Support PIM-SM, PIM-DM, and PIM-SSM Support IGMP Proxy; Support controlled multicast |
| Layer3 Routing | Static/dynamic routing, RIP/OSPF/BGP/ISIS |
| Management | Support CLI, Console port, Telnet, SSH, and WEB configuration management; Support SNMP V1, V2c, and V3 management and support SNTP |
Product Features
| Stability | QoS Capabilities |
|---|---|
| ● Linux operating system ● IPv4/IPv6 dual protocol stack platform ● STP/RSTP/MSTP/ERPS/LACP etc. |
● Support port speed and flow speed limit ● Support Service flow and QoS flow control ● Support SP/WRR/SP+WRR ● Support port-based and service flow-basedmirroring functions |
| Safety Mechanism | Routing Protocol |
| ● Support ACL security filtering mechanism based on MAC, IP, L4 port ● Support Anti-ARP & User Blocking function ● Support DHCP attack automatic protection ● Support DDOS and virus attack protection ● Support DHCP/IP/802.1X etc. ● Support BFD, FlexLink, LACP and ERRP etc. ● Support Remote Loop Detection function ● Support CFM、EFM ● Support Tacacs+, Radius, and Local user authentication |
● Support Static Route ● Support RIP, OSPF,BGP, ISIS ● Support IPV4/IPV6 dual protocol stack ● Support RIPng、OSPFv3 |
| Multi-service Capabilities | Network Management |
| ● Support DHCP Server and DHCP Relay ● Support L2-Tunnel ● Support Ethernet OAM protocol (CFM、EFM) |
● Support CLI based on RS232 serial port, Telnet and SSHv2 ● Support RFC1213 SNMP ● Support WEB-based configure operation ● Support SNMP V1/V2/V3 ● Support FTP & TFTP remote upgrade and download |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
