Part Number: FT-SC-FTO-QC
SC/PC Single-mode Fusion Splice On Fiber Fast/Quick Connector
Fusion Splice-on Connector
Fusion Splice-on Connector is actually an optical fiber fusion, however the welding point is in the inner end of connector, which makes it no necessary for extra protection equipment, such as fiber protection plate(optical fiber splice tray), optical fiber terminal box, optical fiber distribution frame, after it finished splice fusion. Compared to mechanical optical fast connector, this new practical connector can improve the span life of welding point of connector and reduce maintenance cost.
Features
- Used for φ3.0mm,φ2.0mm cable and 3x2mm drop cable etc.
- The fusion splice position can be protected by the heat shrinkable tube inside, not easy broken
- 100% qualified, prolong use life, reduce the Maintenance cost
- The operator can confirm if the splicing is successful by the monitor of fusion splicing machine, to make it have more stability
Applications
- Fiber optic communication system
- Optical access network
- Fiber optic data transmission
- CATV
- Fiber optic equipment
Specifications
| Item | Single mode fiber |
|---|---|
| Fiber diameter | 2.0mm/3.0mm and3x2mm drop cable3.0x2 drop cable |
| Insertion loss | ≤0.15dB |
| Return loss | ≥55dB |
| Repeatability | <0.1dB |
| Interchangeability | <0.2dB |
| Working temperature | -40°C-+80°C |
| Tensile Strength | 60N(6KGS) |
| Connector type | SC/UPC |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
