Part Number: FT-SC-MM-QC
Straight-through Fast Connector
Ferrule in optical fiber straight-through fast connector have no reserved fiber, there is no splice point in V-Groove, fiber end can be checked when construction, and without intermittent points in it.
Features
- Streamlined component design, convenient operation
- 90 seconds (disregard of fiber processing) to complete continuation
- Linkage design, remove ceramic pin compression and optical fiber bent
- Break caused by optical fiber design
- Pre-installed, on-site assembly without end face grinding and consideration
- Matching fluid life impact
- Unique tail clamping mechanism to ensure the tensile strength, security and stability
- Excellent insertion loss and return loss
- All kinds of connectors and end-face grinding are applicable
- Available for 0.9/2.0/3.0mm fiber cable
Specifications
| Connector types | SC,FC | ||
|---|---|---|---|
| dimension | 50mm | ||
| Fiber cable type | 0.9/2.0/3.0mm fiber cable | ||
| Grinding end-face | PC,UPC,APC | ||
| Insertion loss | SM | PC/UPC | APC |
| ≤0.2dB | ≤0.2 dB | ||
| Return loss | SM | PC/UPC | APC |
| ≥45dB | ≥50dB | ||
| Tension test | ≥100N | ||
| Temperature range | -40℃~+75℃ |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
