Part Number: FT-Shufle-OM4-32-X
10m (33ft) Pre-terminated MPO 4x4 Shuffle Trunk Cable, 32 Fibers, 4xMPO-8 APC (Male) to 4xMPO-8 APC (Male), Multimode (OM4), Type 4, LSZH, 0.35dB Max, Breakout 80cm, Magenta
Shuffle Cables provide a structured way to redistribute NIC traffic across multiple switches and network planes, transforming traditionally complex cross-connections into organized, high-density fiber assemblies. In large-scale AI and HPC clusters, where multi-plane architectures multiply physical-layer complexity, Shuffle technology ensures that traffic flows remain balanced, scalable, and logically structured. By predefining fiber mappings and enabling multi-path connectivity, it reduces cabling disorder and operational risk while preserving high performance for latency-sensitive workloads
Multimode Shuffle Fiber Cables are tailored for high-density network architectures. Boasting a revolutionary shuffle design, they enable flexible routing, space-saving installation and reduced cable clutter. Combined with 8° APC connectors for minimized interference, they deliver consistent high-performance transmission, simplified maintenance and enhanced scalability—empowering data centers to keep pace with explosive traffic growth.
Features
● Multi-core, high-density design reduces cable count and saves routing space
● On-site "plug and play", fast installation, improve deployment efficiency
● Ultra-low insertion loss and high return loss ensure link consistency
● LSZH sheath, ensure safe indoor deployment and OFNP Fire Safety-Rated for use in Plenum Air Spaces
● Preorganized Shuffle Assemblies reduce installation time, streamlining deployment in large-scale GPU clusters
● 3-year warranty, lifetime after-sales technical support
Specifications
| Connector Type | MPO Male to MPO Male | Polarity | Type 4 |
|---|---|---|---|
| Fiber Grade | Bend Insensitive | Fiber Count | 4x8F to 4x8F |
| Polish Type | APC to APC | Cable Jacket/Flame Rating | LSZH/OFNP |
| Fiber Mode | OM4 50/125μm | Return Loss | ≥35dB |
| Wavelength | 850/1300nm | Attenuation at 1300 nm | ≤1.0dB/km |
| Insertion Loss | ≤0.35dB | Min. Bend Radius | 7.5mm |
| Attenuation at 850 nm | ≤2.3 dB/km | Breakout Outside Diameter (OD) | 3.0mm |
| Cable Outside Diameter (OD) | 3.5mm | Tensile Strength | 200/660N (Long/Short Term) |
| Breakout Length | 0.8m | Operating Temperatur | LSZH:-20~70°C OFNP:0~70°C |
| Connector Durability | ≥ 500 - 1000 times |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
