Part Number: FT302
CATV EOC slave with 2 RJ45 ports Indoor
FT302 supplies one RF hybrid signal input port, one RF CATV output port and two 100M full-duplex RJ45 output Ethernet ports to FMve access to both TV and computer. FT302 supports bandwidth set, and supports to limit he max uplink and downlink bandwidth.
Features
Good anti-jamming capability with OFDM (kind of MCM, Multi-Carrier Modulation) and cFMnnel-adaptive technology.
- Highly adaptable to network, amplifier and distributor
- Highly effective filter, lower interference to CATV
- Supply VLAN, IGMP and QoS
- Support SNMP, WEB and CLI management
- Support remote software upgrade
- Managed intensively by central EOC, support TELNET management
- No need to configure, start work once connected
Specification
| System Parameter | Technical Index |
|---|---|
| System Bandwidth | Physical layer data rate 200Mbps |
| IP data throughput 100Mbps per channel | |
| Modulation | OFDM;BSPK, QPSK, 1024/256/64/16/8-QAM |
| MAC Protocol | TDMA and CSMA |
| EOC technology | HomePlug AV |
| Carrying Capability | 253 per channel, total 1012 slaves |
| Protocol and Standard | IEEE 802.1Q |
| IGMP v1, v2 | |
| IEEE 802.1P QoS | |
| NMS | WEB; CLI; SNMP |
| Data Interface | Two 10/100Base-TX RJ45 input port |
| Auto MDI/MDIX | |
| Comply with 802.3, IEEE802.3u | |
| TV Interface | One RF port |
| Metric thread F type | |
| Output level: 108dBμV | |
| Insertion Loss: <1.5dB | |
| Impedance: 75Ω | |
| Hybrid Interface | One RF hybrid signal output ports |
| Metric thread F type | |
| Frequency: 2-870MHz | |
| Output Level: 108dBμV | |
| Impedance: 75Ω | |
| Light Indicator | DATA (Cable connection LED) |
| ETH1, ETH2 (Ethernet port LED) | |
| SYS (System LED) | |
| PW (power LED) |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
