Part Number: FT3711A-T/R
1 Channel VGA over Single-mode Optical Fiber Transmitter and Receiver Set with embedded audio FC 20km
FT3711 digitally transmits high-resolution VGA/RGB (up to WXGA) and stereo audio over one fiber, single-mode or multimode, single-core, 1310 nm wavelength. Ideal for point-to-point, point-to-multipoint and drop-and-repeat applications, it supports VGA, SVGA, XGA and WXGA (640 x 480, 1024*768, and 1280*1024, up to 1366 x 768) or RGBHV format.
And VGA Fiber Optic Transmitter should be worked with VGA Fiber Optic Receiver.The price on the website is for Pair.
Features
- CRAFT: uncompressed technology
- highest resolution: 1920x1080
- Transmisson Distance:20km
- Fiber Type: Single-mode Simplex
- Audio: 1 channel bidirectional stereo Audio
- 1-ch VGA/RGBHV video signal and 1-ch stereo audio over one fiber
- 1-ch RS232 data with the same direction (optional bidirectional transmission)
- Sampling clock phase adjustment
- Image brightness adjustment
- Image contrast adjustment
- 10-bit digital video encoded and uncompressed transmission technology
- The parameters could be saved, and also could be saved after power is turned-off
- Plug and play at any time, basically no need to be adjusted
- Automatic identification of input video format, receiver output meets industry-standard video
- Using DC-DC power conversion technology, could effectively resist environmental interference of power
- 4U rack mount, 1U rack mount and stand-alone
- Lower power consumption and free installation, Jitter
Applications
- Remote OB Van/Truck Video Feeds
- Broadcast Studio Camera Feeds
- Long-haul Signal Transport
- TV station/video conference
- Lecture Hall Projector Connectivity
- Medical/Surgical Room Broadcast
- Building to ing video conference calling
- Small corporate campus video links
Product connection diagram
Dimension
Make to Order (Extend information)
| Video Interface | Stereo Audio | Fiber Type | Fiber Port | Data Port | Power Supply | Package |
|---|---|---|---|---|---|---|
| 1 CH VGA | 1 CH Forward 1 channel reverse 1 channel bidirectional |
Single-mode Simplex | FC ST SC LC |
1 channel Forward RS485/RS232/RS422 1 channel reverse RS485/RS232/RS422 1 channel bidirectional RS485/RS232/RS422 |
AC110~260V | stand-alone 1U rack mount |
Note:
1.Fiber Port: FC and ST is available,and for SC/LC connector, F-tone will provide you a corresponding patch cable for connector conversion for free
2.1 U rack mount:The standard is with 4 slots,F-tone will offer you dam-board by free when some slots is empty.
Ordering information
| VGA/RGBHV Fiber Optic Transmitter and Receiver | |
| FT3711-T/R | 1-ch VGA, single fiber |
| FT3711A-T/R | 1-ch VGA, 1-ch bidirectional audio, 1-ch RS232, single fiber |
| FT3711B-T/R | 1-ch VGA, 1-ch bidirectional audio, 1-ch RS232, single fiber |
Note:Our standard single mode is 20KM, multimode is 2KM, please inform us your fiber mode and distance, when you place an order.
- 1U rack support 4 VGA cards.
- 4U rack support 13 pcs of VGA card with dual power
- 4U rack support 15 pcs of VGA card with single power
| Video | |
| No. | 1-channel |
| Video type | RGB with single and sync H,V |
| Input level | 0.7Vp-p |
| Output level | 0.7Vp-p |
| Bandwidth (-3 dB) | 300MHz |
| Bit width | 10bit |
| Resolution | Max1080P@60Hz |
| Interface | DB-15 |
| Audio | |
| No. of channels | 1-ch bidirectional |
| Input/output level | 5Vp-p,unequilibrium |
| Total harmonic distortion | ≤1% |
| Bandwidth (-3 dB) | 20~20KHz |
| Audio coding | 24bit |
| Input/output impedance | 600Ω or 100KΩ |
| Weighted SNR | ≥90 dB |
| Connector | Standard 3.5 mm stereo headphone jack |
| RS232 indication | |
| Channel | 1-ch duplex |
| Input/output interface? | Terminal block |
| Signal rate | ≥115200bps |
| Signal level | RS232 standard level |
| Optics | |
| Wavelength | 1310nm |
| Fiber optic | Single-mode |
| Max. link loss | 12dB（option） |
| Output optical power | 10dBm |
| Receiver sensitivity | ≥20dBm |
| Data rate | 2.5 |
| Connector | FC (ST option) |
| PS2 | |
| No. | 2 (for keyboard and mouse) |
| Compatibility? | Using PS2 to USB cable, it works fine |
| Power and environmental indication | |
| Freestanding power | 5W |
| Dimension | 237mm * 180mm *28.5mm(high) |
| Power adapter | 220VAC to 12VDC/1A |
| Temperature rage | -40°C to +70°C |
| Relative humidity | < 95% (no condensation) |
