Part Number: FTOFSM-G652-X
G.652.D FullBand® Low Water Peak Single-mode Fiber 50.4km Length in Spool
FullBand® low water peak dispersion unshifted Single-mode fiber is designed specially for optical transmission systems operating over the entire wavelength window from 1260 nm to 1625 nm. By suppressing the water peak that occurs near 1383 nm in conventional single mode fiber due to hydroxyl (OH-) ions absorption, FullBand® fiber is able to open E-band (1360-1460nm) for operation, and consequently provides 100 nm more usable wavelengths.
Applications
Thanks to its broad usable optical spectrum and outstanding optical performance, FullBand® fiber is the optimum choice that supports various applications such as Ethernet, Internet Protocol (IP), Asychronous Transfer Mode (ATM), Synchronous Optical Network (SONET) and Wavelength Division Multiplexing (WDM). FullBand® fiber provides more bandwidth for backbone, metropolitan area and access networks.
Product standards
FullBand® fiber complies with or exceeds the ITU-T Recommendation G.652.D and the IEC 60793-2-50 typeB1.3 Optical fiber Specification.
Characteristics
● Designed for operation over the full optical spectrum from 1260-1625 nm, which provides 50% more usable wavelengths and hence the transmission capacity is increased
● Outstanding optical performance supporting high-speed transmission technologies such as DWDM and CWDM
● Being compatible with existing 1310 nm equipment
● Good protection and excellent strip force stability
● Accurate geometrical parameters that insure low splicing loss and high splicing efficiency
Specification
| Characteristics | Conditions | Specified values | Units | |
|---|---|---|---|---|
| Optical Characteristics | ||||
| Attenuation | 1310nm | ≤0.34 | [dB/km] | |
| 1383nm(after H2-aging) | ≤0.34 | [dB/km] | ||
| 1550nm | ≤0.20 | [dB/km] | ||
| 1625nm | ≤0.24 | [dB/km] | ||
| Attenuation vs. Wavelength Max. α difference |
1285-1330nm, in reference to 1310nm | ≤0.03 | [dB/km] | |
| 1525-1575nm, in reference to 1550nm | ≤0.02 | [dB/km] | ||
| Dispersion Coefficient | 1285-1340nm | -3.5 to 3.5 | [ps/(nm·km)] | |
| 1550nm | ≤18 | [ps/(nm·km)] | ||
| 1625nm | ≤22 | [ps/(nm·km)] | ||
| Zero Dispersion Wavelength(λ0) | -- | 1300-1324 | [nm] | |
| Zero Dispersion Slope(S0) | -- | ≤0.092 | [ps/(nm2·km)] | |
| Typical Value | -- | 0.086 | [ps/(nm2·km] | |
| PMD | Maximum Individual fiber | -- | ≤0.1 | [ps/√km] |
| Link Design Value（M=20，Q=0.01%) | -- | ≤0.06 | [ps/√km] | |
| Typical Value | -- | 0.04 | [ps/√km] | |
| Cable Cutoff Wavelength (λCC) | -- | ≤1260 | [nm] | |
| Mode Field Diameter（MFD） | 1310nm | 8.7-9.5 | [μm] | |
| 1550nm | 9.8-10.8 | [μm] | ||
| Effective Group Index of Refraction（Neff ） | 1310nm | 1.466 | -- | |
| 1550nm | 1.467 | -- | ||
| Point Discontinuities | 1310nm | ≤0.05 | [dB] | |
| 1550nm | ≤0.05 | [dB] | ||
| Geometrical Characteristics | ||||
| Cladding Diameter | -- | 125.0±0.7 | [μm] | |
| Cladding Non-Circularity | -- | ≤1.0 | [%] | |
| Coating Diameter | -- | 235-250 | [μm] | |
| Coating-Cladding Concentricity Error | -- | ≤12.0 | [μm] | |
| Coating Non-Circularity | -- | ≤6.0 | [%] | |
| Core-Cladding Concentricity Error | -- | ≤0.6 | [μm] | |
| Curl(radius) | -- | ≥4 | [m] | |
| Delivery Length | -- | Up to 50.4 | [km/reel] | |
| Environmental Characteristics | 1310nm, 1550nm & 1625nm | |||
| Temperature Dependence Induced Attenuation | -60℃ to +85℃ | ≤0.05 | [dB/km] | |
| Temperature-Humidity Cycling Induced Attenuation | -10°C to +85°C, 98% RH | ≤0.05 | [dB/km] | |
| Water Immersion Dependence Induced Attenuation | 23°C，for 30 days | ≤0.05 | [dB/km] | |
| Damp Heat Dependence Induced Attenuation | 85°C and 85% RH，for 30 days | ≤0.05 | [dB/km] | |
| Dry Heat Aging | 85℃, for 30 days | ≤0.05 | [dB/km] | |
| Mechanical Specifications | ||||
| Proof Test | -- | ≥9.0 | [N] | |
| -- | ≥1.0 | [%] | ||
| -- | ≥100 | [kpsi] | ||
| Macro-bend Induced Attenuation | 100 Turns Around a Mandrel of 30 mm Radius | 1625nm | ≤0.05 | [dB] |
| 100 Turns Around a Mandrel of 25 mm Radius | 1310nm and 1550nm | ≤0.05 | [dB] | |
| 1 Turn Around a Mandrel of 16 mm Radius | 1550nm | ≤0.05 | [dB] | |
| Coating Strip Force | typical average force | 1.5 | [N] | |
| peak force | 1.3-8.9 | [N] | ||
| Dynamic Fatigue Parameter(nd) | -- | ≥20 | -- | |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
