Part Number: FTS50A
5.0mm Stainless Steel Tubing and Sleeves, SUS304 Silver Coloe, price for 10m Length,
Introduction
F-tone FT05SS Stainless Steel Tubing and FTS50x Sleeves provide a high degree of fiber protection. The FT05SS is the same tubing used in our SMA Fiber Bundles. Its all-metal jacket prevents visible and IR light from entering through the length of the patch cable. The FTS50x sleeves effectively replace the strain relief boot used with our standard furcation tubing and shield the connection from dust, dirt, and other external contaminants.
The bare fiber can be fed directly into the tubing, which does not contain an inner tube, Kevlar threads, or a pull string. If desired, the fiber can be fed into our FT030 tubing (which does feature a pull string) before being put into the stainless steel tubing for added convenience and protection.
Please note that the maximum continuous length we can provide for this tubing is 100 m.
Specifications
| Item # | Inner Diameter of Fiber Connector Side |
FC/PC Connectors |
FC/APC Connectors |
SMA Connectors |
ST Connectors |
LC Connectorsa |
|---|---|---|---|---|---|---|
| FTS50A | 0.138" - 0.150" (3.50 - 3.81 mm) |
30126C3, 30128C3, 30126C9, | 30126A3, 30126A9 | 30126B1 | - | |
| FTS50B | 0.153" - 0.165" (3.89 - 4.19 mm) |
- | - | - | 10140G1 10127C |
- |
| FTS50D | 0.178" - 0.190" (4.52 - 4.83 mm) |
, 30125D2, , 30140E1 | 30080K2, 30127A3 | - | - | - |
- Our Ø5.0 mm stainless steel tubing and sleeves are not compatible with LC connectors.
- Hytrel® is a registered trademark of DuPont Polymers, Inc.
- Kevlar® is a registered trademark of DuPont Safety & Construction, Inc.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
