Simplex Singlemode 9/125 OS2, FRP Strength Member, LSZH Indoor FTTH Fiber Patch Cable

Simplex Singlemode 9/125 OS2, FRP Strength Member, LSZH Indoor FTTH Fiber Patch Cable

View full details

Part Number: FTTH-SM-SX-FRP-LSZH-1M

Indoor FTTH drop cable is used to connect to the end users' homes, widely applied in access networks and FTTH indoor cabling.

Simplex Singlemode 9/125 OS2 FRP Strength Member LSZH Indoor FTTH Fiber Patch Cable
With easy accessiblility to the fiber and simple installation, FTTH cable can be directly connected to the homes. It is suitable for connecting with communication equipment, and used as access building cable in premises distribution system. The optical fibers are positioned in the center of cable and two parallel strength members are placed at the two sides. The metal messenger wire is on the top of cable for aerial installation and outside of all is covered with the black LSZH sheath. Also, customers can specify your required connectors.
Cable Type FTTH Indoor Patch Cable Fiber Count Simplex
Jacket Material LSZH (Black) Fiber Type Singlemode G652D/G657A1
Cable Diameter 2.0x5.2mm Cable Weight 18kg/km
Strength Member Material FRP Tensile Strength (long/short term) 300/600N
Crush Load (long/short term) 1100/2200 (N/100mm) Bending Radius (long/short term) 15D/20D (mm)
Installation Temperature -20 to +60°C Operation Temperature -40 to +70°C
Feature and Application
Access NetworksLAN (Local Area Network)Fiber Optic Communication SystemFTTH (Fiber to The Home) Indoor BuildingOptical fiber connected and transmitted equipment

Good mechanical and environmental characteristic Simple structure, light weight and high practicability Low smoke zero halogen and flame retardant sheath Novel flute design, easily strip and splice, simple installation and maintenance Two parallel FRP strength members ensure good performance of anti-electromagnetic and crush resistance Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
Ideal Solution by FTTH Indoor Fiber Patch Cable
Indoor FTTH drop cable is used to connect to the end users' homes, widely applied in access networks and FTTH indoor cabling.
Packaging & Labeling
This easy to take and well-protected fiber optical cable package has been labelled and marked by F-tone.COM as default.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
