Generic Compatible 10G DWDM XFP Optical Transceiver Module (SMF, C17-C61, 80km, LC, DDM)
The Generic compatible DWDM-XFP-ZR-XX 10G SXFP module features an LC duplex connector and supports up to 80km over single-mode fiber (SMF) G.652/655. Operating at a nominal DWDM wavelength of C17 channel - 1563.86nm to C61 channel - 1528.77nm, as specified by ITU-T, it's designed for DWDM network equipment connectivity.
Manufactured by F-tone, this 10GBASE-DWDM XFP module complies with SFP+ MSA Compliant, CPRI, and eCPRI specifications. It's extensively tested for compatibility with H3C equipment like Ethernet switches, enterprise routers, and server NICs. This third-party DWDM 10G XFP module offers a cost-effective alternative to brand OEM XFP 10G transceiver.
DWDM 10G XFP optics are perfect for 10 Gigabit Ethernet (10GbE) fiber connections, ideal for Long Haul DWDM Solutions in metro access and core networks.
| Model Name | DWDM-XFP-ZR-XX | Vendor Name | F-tone |
| Form Factor | XFP | Data Rate | 10Gbps |
| Wavelength |
C17-C61 1563.86nm - 1528.77nm |
Distance | 80km@G.652 |
| Connector | LC Duplex | Cable Type | OS2 SMF |
| Transmitter Type | EML | Receiver Type | APD |
| TX Power | -1~+4dBm | Receiver Sensitivity | <-24dBm |
| Power Consumption | <1.5W | Modulation Format | NRZ |
| DOM | Support | Bit Error Ratio (BER) | 1E-12 |
| Protocols | SFP+ MSA Compliant, CPRI, eCPRI | Warranty | 5 Years |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series
HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series
-
AVAGO HFBR-2521ETZ Compatible Domestic Alternative Optical Module
Regular price $0.00Regular price -
AVAGO HFBR-1521ETZ Compatible Domestic Alternative Optical Module
Regular price $0.00Regular price -
AVAGO HFBR-1528Z Compatible Domestic Alternative Optical Module
Regular price $0.00Regular price -
AVAGO HFBR-2528Z Compatible Domestic Alternative Optical Module
Regular price $0.00Regular price
Power and Wavelength Testing
Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.
Traffic Testing
Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.
Optical Performance Testing
Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.
End Face Testing
Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.
Various Switch Tests
Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.
