H3C SFP-FE-SX-MM1310-A Compatible 100BASE-FX Transceiver Module-F-tone

H3C SFP-FE-SX-MM1310-A Compatible 100BASE-FX Transceiver Module-F-tone

View full details

Transceivers Type

SFP Optical Transceiver

Compatible

200+ Vendors

Specifications

H3C SFP-FE-SX-MM1310-A Compatible 100BASE-FX SFP Transceiver Module (MMF, 1310nm, 2km, LC, DOM)

The H3C SFP-FE-SX-MM1310-A Compatible Transceiver supports link lengths of up to 2km over multi-mode fiber (MMF) using a 1310nm wavelength through an LC connector. This transceiver has been meticulously tested for compatibility with a wide range of H3C devices, including switches, routers, servers, network interface cards (NICs), and more. Notably, it boasts low power consumption and hot-swappable capabilities, making it an excellent choice for various applications, including ISP Fast Ethernet communication links, Enterprise LAN & SAN Networks, Data Center LAN & SAN Networks, and other optical links.



Part Number FT-SFP-0102D Vendor Name F-tone
Form Factor SFP Max Data Rate 155Mbps
Wavelength 1310nm Max Distance 2km
Connector Duplex LC Transmitter Type 1310nm FP
Cable Type MMF Receiver Type PIN
TX Power -18.0~-10.0dBm Receiver Sensitivity < -26.0dBm
Protocols MSA Compliant Operation Temperature 0 to 70°C (32 to 158°F)

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

HFBR-1414TZ | HFBR-2412TZ AVAGO compatible full series

View all

HFBR-1521Z | HFBR-2521Z | AFBR-1629Z | HFBR-2629Z AVAGO compatible full series

View all

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.
