Low-speed Transparent Transmission Module
● MINISFF package structure
● Available data rates include 0~100M and others
● Optional long-distance and short-distance transmission
● Optional DWDM 100G ITU GRID C-band wavelengths
● Peak-to-peak jitter of the combined optical transmitter and receiver modules is less than 60ps
● LVDS input and output
Application
● Transparent transmission of RS232/485 and other low-speed buses
Ordering Information
| Model | Wavelength (nm) | Data Rate | Transmission Distance (km) | Digital Diagnostic | X |
| FTMF-DxxLC-10x | 100GHZ DWDM | 0~100M | 10 | N | E:Commercial grade I: Industrial grade M: Military grade |
| FTMF-C55LA-02x | 1550 CWDM | 0~20 | 2 | N | E:Commercial grade I: Industrial grade M: Military grade |
| FTMF-DxxLB-80x | 100GHZ DWDM | 0~50M | 80 | / | E:Commercial grade I: Industrial grade M: Military grade |
Note: Undesignated tolerances: ±0.25mm
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
