10/100M Dual Fiber 1550nm 80km External Power Supply Mini Ethernet Media Converter

Part Number: MFMC-DF-SM-80

Mini Ethernet Media Converter 10/100M Dual Fiber 1550nm 80km

Media converters can be used anywhere in the network to integrate newer technology with existing equipment to support new applications, technologies and future growth. Instead of costly, across-the-board upgrades, media converters can extend the productive life of the existing cabling as well as the active equipment.

F-tone.COM supply 10/100Base Ethernet Fiber Media Converters, 1000Base Gigabit Fiber Media Converter,SFP Fiber Media Converter, Options in singlemode dual fiber, multimode dual fiber and singlemode single fiber. We also supply Media Coverter Chassis, the 1U height 12 slots media converter rack mount chassis specially designed for accommodating chassis-based mini Media Converters.

Features

• AutoCross™: Automatically detects and configures the twisted pair port on the converter to the correct MDI or MDI-X configuration.
• Link Pass Through: Link Pass Through is a troubleshooting feature that allows the media converter to monitor both the fiber and copper RX ports for loss of signal.
• Automatic Link Restoration: The medio converters will automatically re-establish link in all network conditions.
• Selectable speed setting: The converter can be set to 10Mbps or 100Mbps. Both copper and fiber ports are automatically set to the same speed. Devices connect to duplex mode of link partner.

Key Features

• 10/100Base-TX UTP to 100Base-FX fiber media convertion
• Support IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX standards
• A19Choice of SC, BiDi or other connectors for multimode and singlemode
• DIP switch to set different configurations
• LFP (Link Fault Pass-through) support
• Compact package size
• The mini 10/100Base-TX to 100Base-FX Media Converter is fully compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX protocols. The converter can support auto MDI-MDIX function, flow control for full and half duplex operation, link fault pass through function (LFP), etc.
• A DIP switch is placed at the bottom of the case. Depend on different configurations, the user can set the different operating mode (UTP port speed 10M or100M, full or half duplex mode, pass through mode, LFP enable or disable)

Applications:

Extend Ethernet Network Distances
It use the 10BASE-T to 10BASE-FL speed setting (back-to-back) to extend the distance between two 10BASE-T devices up to 100km. using single mode fiber without a repeater.

Extend Fast Ethernet Network Distances
It use the 100BASE-TX to 100BASE-FX setting to extend the distance between any two 100BASE-TX devices up to 100km. using single mode fiber. Or interface directly with a 100BASE-FX compliant port on any device to provide a 100BASE-TX port interface.

Technical Specifications

• Data Rates:10/100 Mbps (802.3 10Base-T/802.3u 100Base-T),100Mbps (100Base-FX)
• Input Power Requirements:
  Input voltage:DC 5-12V or AC 6-12V 50/60Hz (optional)
  Power consume:3 Watts maximum
• Environmental Conditions:
  Operating temperature:0℃ to 40℃
  Cooling:A28
  Storage temperature:-20℃ to +85℃
  Operating Humidity:90% max, non-condensing


• Mechanical Specifications:
  Case Material:Iron
  Case Color:Black
  Net Weight:150g approx. /unit
  Dimensions:60 (W) x 20 (H) x 90 (L) (mm)
  Do not include transceiver length
  Warranty : 2 year hardware warranty
  Specifications subject to change without notice

Label Customized

Note:Neutra or customized label are available per your requirements.please feel free to contact us at [email protected] for more details.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
