Part Number: MGTSV-4A1.b
MGTSV Flame-retardant Mining Fiber Optic Cable, Single Armor, Double Jackets, 4 OM1 Multimode Optical Fibers
MGTSV is suitable for coal, gold, iron ore and other mines. It has the flame retardant, rodent resistance property, so it is a good choice for mines. Especially for the accident-prone land mines, to ensure smooth communication, reduce losses when the accident happens.
The steel armor helps to protect the cable from rat bite, ensures bullet proof ability. Double jackets structure have nice properties of moisture resistance and crush resistance. Besides, the out sheath is flame retardant. Loose tube material itself has good hydrolysis resistance. Waterproof performance ensures the safety of underground mine.
Item Details
- Fiber Count: 4 Fibers
- Fiber Type: 62.5/125μm Multimode
Cable Structure
- Good flame retardant performance.
- High strength loose tube that is hydrolysis resistant.
- Double sheathes and single armor providing excellent crush resistance, water proof, and avoiding rat bite.
- Loose tube wrapped by non-weaven tape has the water blocking ability.
- Special tube filling compound ensure a critical protection of fiber.
- Blue PVC jacket: Flame retardant, the blue color is easy to identify.
- Crush resistance and flexibility.
- Professional usage for the coal industry
- Tunnel shaft
- Mine
Package
Package 2: usually for outdoor cable, heavy weight cables
Usually for each roll, the cable length is 2km, but we could provide customized package for different cable lengths.
Mark
Usually we only attach Test Report on the out package of the cable, but we could also mark as your requirements, such as:
1. Company Name
2. Cross /Net weight
3. Drum No: XX
4. Cable Length : XX
Cable production throughout the chart
| Cable Count | Cable Diameter | Cable Net Weight |
Minimum allowable Tensile Strength (N) |
minimum allowable Crush Load (N/100mm) |
Minimum Bending Radius (mm) |
Storage Temperature |
|||
| （mm) | （Kg/km) | Short term | Long term | short term | long term | Dynamic | Static | （℃） | |
| 2-30 | 12.7 | 180 | 600 | 1500 | 300 | 1000 | 20D | 10D | -40 - +70 |
| 32-66 | 14.0 | 240 | 600 | 1500 | 300 | 1000 | 20D | 10D | -40 - +70 |
| 62-72 | 15.1 | 290 | 600 | 1500 | 300 | 1000 | 20D | 10D | -40 - +70 |
| 74-144 | 16.0 | 360 | 600 | 1500 | 300 | 1000 | 20D | 10D | -40 - +70 |
| G.652 | 50/125µm | 62.5/125µm | ||
| Attenuation (+20°C) (dB/km) |
@850nm | ≤3.0 | ≤3.0 | |
| @1300nm | ≤1.0 | ≤1.0 | ||
| @1310nm | ≤0.36 | |||
| @1550nm | ≤0.22 | |||
| Bandwidth (Class A) (MHz·km) | @850nm | ≥600 | ≥200 | |
| @1300nm | ≥1200 | ≥600 | ||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | ||
| Cable Cut-off Wavelength λcc (nm) | ≤1260 |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
