Part Number: MN-3GSDI-1Vv1D-T/RL
Mini HD-SDI/3G-SDI Video Digital Optical Converter
F-tone Mini HD-SDI/3G-SDI video digital optical converter adopts international advanced all-digital gigabit optical fiber transmission technology, the HD-SDI/3G-SDI video signal can be transmitted through one fiber with non- distortion, high-quality, long-distance transmission. This series of video to fiber converter has stable performance, clear picture quality, and high stability with LED status indication on the body of device. The working status of devices can be visually observed. Besides, the switch value, voltage, working status and other reverse useful signal information can be controlled by RS485 or RS232.This ensures our devices more flexible when different customers’ request comes.
Features
þ Extend uncompressed multi-rate 3G-SDI, HD-SDI or SD-SDI video over fiber
þ Support SMPTE 424M, SMPTE 292M, SMPTE 259M or DVB-ASI compliant
þ With clock recovery, clock shaping
þ Support embedded digital audio stream
þ Single-mode fiber support for distance up to 20 km
þ Real-time video transmission with exceptional quality and resolution
þ LED status provide prompt indication of operating parameters
þ No EMI or RFI and no ground loops
þ Tailored made according to customers specifications, providing OEM
Technical Parameters
| Optical | Wavelength | 1310nm&1550nm |
|---|---|---|
| Fiber Type | Single mode, single fiber | |
| Distance | 20km | |
| Fiber Interface | LC | |
| SDI Video | Video Interface Number | 2 |
| Physical Interface | BNC | |
| Max Resolution | 1920 x 1080 @ 60Hz | |
| Video Input and Output Impedance | 75Ω (unbalanced) | |
| Video Input/out put Voltage | Typical:1Vpp,Min 0.5Vpp, Max 1.5Vpp | |
| Video Bits Rate | Max 2.97Gb/s | |
| Video SDI standard | 270Mbps(SD-SDI),1.485Gbps/M(HD-SDI),SMPTE425M3Gb/s Mapping(3G-SDI),SMPTE424M 3Gb/s serial interface(3G-SDI) | |
| Data | Physical Interface | The industry standard connecting terminal |
| Interface Signal |
RS485/RS422/RS232/ Manchester |
|
| Baud Rate | 0-400Kbps | |
| BER | < 10 -9 | |
| Operation Mode | Full duplex / half duplex | |
| Electrical & Mechanical | Input Power Requirements | DC 5V |
| Power Adapter | AC 100V~240V | |
| Dimensions | 10.5*4.2*2.2cm | |
| Packing | 23.3*13*3.8cm | |
| Weight | 0.4kg | |
| Environmental | Operating temperature | -20°C ~ +75°C |
| Storage temperature | -40°C ~ +85°C | |
| Working humidity | 0% ~ 95% (non-condensing) | |
| MTBF | >100,000 hours |
Connection Diagram
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
