Part Number: NWC-Q
NWC Patented Quick Assembly SC connector
The NWC Quick Assembly SC connector can provide a quick and easy termination of fibers in the field.
Both SC singlemode and multimode connector options are available for 900 micron and 3mm drop cable application, allowing the installer to terminate and make connection in 3 minutes in the field.
This connector system doesn't need any requirement such as epoxy, adhesive and costly curing ovens.
Features
- Field installable, Cost effective, User friendly
- No epoxy and polishing required
- Quick and easy fiber termination in the field
- Visual indication of proper termination
- Reliable and superior optical performance
Specification
Connector Type:SC Type
Insertion Loss:( Max 0.5dB)
Reflection Typical:< -40 dB
Tensile: Strength
900um :5N
3mm:30N
Connector Durability:< 0.2 dB (After 200 mating)
Operating Temperature: -40℃ ~ +85℃
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
