Part Number: OLS-650-4BT
650nm Optical Light Source, Bench-top Stabilized Laser Source 650nm Max 4 Channels
Features
1. Desktop design four-channel interface Independent switch Good heat dissipation Save battery Low power direct power supply Safe and reliable, suitable for production workshop.
2. using fiber output, high fiber input power, must be used with fiber jumper + adapter transfer to protect the laser damage.
3. 2.5mm universal interface design.
4. The transmission distance in the fiber can reach 15Km.
5. It is easy to find the precise part of the fiber operation and microbending.
6. four-channel high-power design, suitable for high-volume production lines.
Application
- Fiber Patchcord manufacturing
- Lab Research
- Fiber Optic Testing
- College Educations
Specifications
| Supported Channel | 4 |
|---|---|
| Maximum Output Power（mW） | 10 |
| Output power stability（dB） | 土0.005（15min/10mW) |
| 土0.005（8Hour/10mW) | |
| Dimension（mm) | 235x380x140 |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
