LC UPC to LC UPC Short Boot Duplex OM3 Multimode Fiber Patch Cable

LC UPC to LC UPC Short Boot Duplex OM3 Multimode Fiber Patch Cable

View full details

Part Number: OM3-LCU-LCU-DX-FT-SB

LC UPC to LC UPC Short Boot Duplex 50/125μm OM3 Multimode Fiber Optic Cable

The short boot structure is particularly for high density applications with tight space requirements. When used with bend insensitive fiber, the attenuation during bending or twisting can be reduced and this will make the installation and maintenance of the fiber optic cables more efficient. Therefore, it can be used in central offices, passive optical networks (PON), FTTx, data centers, and any places fiber patch cables are needed.

This 50/125 OM3 multimode fiber optic cable is ideal for connecting 10G SR, 10G LRM, SFP+ transceivers etc. for 10G/40G/100G Ethernet connections and is the preferred fiber specification for 10G Ethernet connections.

Item Spotlights

  • 60% Shorter in Boot Length & 30% Reduction in Overall Connector Length
  • 12mm Short Boot Allows Connection in Compact Space
  • No Heat Shrink System Improves Cable Flexibility
  • PVC (Riser) Flame-retardant Jacket
  • Grade A Precision Zirconia Ferrule Connectors Ensure Low Loss
  • Bend Insensitive Fiber & 7.5mm Min. Bend Radius
  • Compliant to TIA-604 (FOCIS)

Description

Connector Type LC UPC to LC UPC Boot Type 12mm Short Boot
Fiber Count Duplex Fiber Mode OM3 50/125μm
Cable Jacket PVC Cable Diameter 2.0mm
Insertion Loss ≤0.3dB Return Loss ≥30dB
Wavelength 850/1300nm 10G Ethernet Distance 300m at 850nm
Attenuation at 850nm 3.0 dB/km Attenuation at 1300nm 1.0 dB/km
Min. Bend Radius
(Fiber Core)		 7.5mm Min. Bend Radius
(Fiber Cable)		 20/10D (Dynamic/Static)
Tensile Strength
(Long Term/Short Term)		 90N/150N Polarity A (Tx) to B (Rx)
Operating Temperature -20~70°C Storage Temperature -40~80°C

Product Highlights

  • Upgraded Structure Means Better Product Experience
The short boot and no heat shrink tube design make the cable easily pass through the narrow space without sacrificing performance.
12mm Short Boot Structure
30% Shorter in overall connector, more cabling possibilities in limited space.		 No Heat Shrink Tube Design
Improves the cable flexibility without damaging transmission performance.


Custom and OEM

1. Customize Jacket Materials

PVC OFNP LSZH OFNR


2. Customize Cable Color

Red Blue Grey Purple


3. Customize Cable Connector

D4 SMA905 VF45 MU


4. Customize Cable Length

5M 10M 50M 100M


5. OEM Label, Printing and Boot Color


NOTE: If you need customize others, welcome to contact [email protected].


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
