Part Number: OPM-ST-3223
ST-3223 VFL Optic Power Meter
Optical Power meter and VFL integrated in one unit, this tester allows to perform both optical power/loss measurements and Fiber faults tracing visually.
ST-3223 VFL Power Meter is an ideal tester used in quickly mechanical splicing and FTTx networks.
Optical Port: FC, SC, ST interchangeable supports various optical connectors.
Specifications
| Model | ST-3223 |
| Operating wavelength(Power Meter Module) | 1310 1490 1550 850 1300 1625 |
| Detector Type | InGaAs |
| Out put power(VFL module) | 1mW |
| Power Measurement Range | -70~+3dBm |
| Uncertainty | ∮0.5dB |
| Resolution | 0.01 |
| Operation temperature | -10~+60 |
| Storage Temperature | -25~+70 |
| Auto-off function | Yes, Auto-off after 10minutes idle time |
| Battery Life @ OPM | 180 hours |
| Battery Life @ VFL | 60 hours |
| Power Supply | 3pcs AA Batteries |
| Weight | 700g (including batteries) |
| Size | 192*102*50 |
Standard Packages
| MODEL | INCLUDES |
|---|---|
| ST-3223 | VFL Power Meter, 3pcs alkaline batteries, User Manual, Cotton swabs and Soft carrying case. |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
