Part Number: PCAR-200L02SA
AR-Coated Multimode Fiber Patch Cable 400 - 700nm SMA905 Connector 2M
AR-Coated Multimode Patch Cables for 400 - 700 nm (SMA905 Connectors)
| Item # | Fiber Type | Core | Cladding | Operating Wavelength Rangea |
Fiber Attenuationb (Click for Graph) |
NA | AR Coating | AR Plot |
Length | Bend Radius | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Short Termc | Long Term | ||||||||||
| 50L02S-A | FG050LGA | Ø50 µm ± 2% | Ø125 ±1 µm | 400 - 700 nm | 0.22 | Ravg < 0.75% from 350 - 700 nm |
2 +0.075/-0.0 m | 23 mm | 30 mm | ||
| 105L02S-A | FG105LCA | Ø105 µm ± 2% | Ø125 ±1 µm | 400 - 700 nm | 23 mm | 30 mm | |||||
| 200L02S-A | FG200LCC | Ø200 ± 8 µm | Ø240 ± 5 µm | 400 - 700 nm | 23 mm | 24 mm | |||||
- The operating wavelength range of the patch cable is determined by the wavelength range of both the bare fiber and AR coating.
- The AR coating is designed for 350 - 700 nm, but the fiber attenuation is higher in the UV and limits the operating wavelength range of the patch cable.
- Limited by the minimum bend radius of the outer FT05SS tubing.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
