Part Number: PMCO-9-FCA
In-Line Fiber Optic Polarization Controller for Ø900 µm Tight-Buffer Fiber FC/APC
Converts an Arbitrary Input Polarization State to Any Desired Output Polarization State
Insensitive to Wavelength Variations, Vibrations, and Fiber Variations
Versions for Ø250 µm Bare Fiber or Ø900 μm Tight-Buffer Fiber
Features
- Low Insertion Loss
- All-fiber structure
- Compact design
Applications
- Fiber sensor
- Test equipment
- Fiber-optic laser
Performance Specifications
| Parameter | Values |
|---|---|
| Channel Wavelength (nm) | 1260-1620 |
| Insertion Loss (dB) | ≤0.5 |
| Number of Paddles | 3 |
| Return Loss(dB) | >55 |
| Fiber Type | SMF-28e |
| Opterating Temperature (℃) | -40~+85 |
| Storage Temperature (℃) | -40~+85 |
| Dimension(L×W×H) | L120.5 x W25 x H58 |
Ordering Information
| Center wavelength | Fiber Type | Fiber Length | In/Out Connector |
|---|---|---|---|
| 1260~1620nm | 900um | 1=1m | 1=FC/APC |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
