POB Optical Transceiver,10G,24Tx24Rx

POB Optical Transceiver,10G,24Tx24Rx

View full details

POB Optical Transceiver,10G,24Tx24Rx

Product Brief
The POB 24-channel parallel optical transceiver module enables photoelectric signal conversion between 24 parallel optical transmit channels and 24 parallel optical receive channels. It is suitable for high-density parallel optical interconnection, optical backplane interconnection, radar-to-processor interconnection, server-to-memory array interconnection, and high-definition audio/video optical transmission. Currently, it has been widely applied in aerospace, electronics, radar, marine, ordnance, and other fields.
Features
● Central wavelength: 850nm
● Single power supply: 3.3V DC
● Equipped with I2C communication monitoring function
● Per-channel transmission rate: 10.3125Gbps
● MT optical interface, LGA spring-loaded crimp electrical interface
● High reliability, low power consumption, large bandwidth, small form factor
The main performance index

Parameters

Min

Typ

Max

Unit

Operating Voltage

3.14

3.3

3.46

V

Operating Temperature

-40

+25

+70

℃

Operating Current

-

-

2500

mA

Single-channel Rate

-

10.3125

-

Gbps

Transmission Distance

0.5

-

100

m

Central Wavelength

840

850

860

nm

Average Transmit Optical Power

-3

-

+1.5

dBm

Extinction Ratio

3

4

-

dB

Receiver Sensitivity

-

-

-10

dBm

Saturation Optical Power

+1

-

-

dBm

Size diagram(mm)

Ordering Information

FTMP-24TR1X-02

X

-XX

-XX

F-tone 24CH Optical Transceiver,10G/CH

E:Commercial grade

100mm
The tail fiber length(customize)

MT: MT tail fiber output
MP:MPO tail fiber output

I: Industrial grade

M: Military grade
