PSE6504G 5-Port GbE Switch witch 1~4 Port POE

Part Number: PSE6504

5-Port GbE Switch witch 1~4 Port POE PSE6504G

Product Overview

Modern business networks are used for increasingly diverse applications – traditional data streams, VoIP voice traffic, video output from digital security cameras and remote control devices to name a few. The range of devices attached to today’s converged network often need to be supported not just in terms of data –equipment such as VoIP IP telephones and Wireless Access Points frequently need to be powered in physical locations where mains power is not available or difficult to deliver. Providing power to such devices via an Ethernet UTP cable is an elegant and easy to implement solution.
The 5-Port 10/100/1000Mbps PoE Plus Switch offers advance switching controls and provides power to network devices using Ethernet cables. This scalable and cost effective solution allows a managed network to efficiently expand to previously unattainable levels.
The feature rich 5-port GbE switch offers advanced network management, Link Aggregation, Trunking and QoS technology to meet the accelerating demand for secure manageable networks. LED displays show device status for easy power management and troubleshooting.PoE technology conveniently eliminates the need to install networked devices, such as PSE5000 Series IP cameras and access points, near a power outlet, thereby reducing equipment and installation costs.
compatible to IEEE802.3af/at. It can power both existing 10/100/1000 Base-T network devices Wi-MAX and wireless IEEE 802.11n access points.

Ordering Information

Features

• Up to 30W of Power on
• IEEE 802.3af/at Compliant with 2-event classification
• IEEE 802.3af/af backward compatible
• Compatible With All IEEE 802.3af or Legacy
• Safe: Low Power Devices Receive Only the Power They Need
• Safe and Reliable Power to WLAN Access Points
• Automatic Detection and Protection of Non–standard Ethernet Terminals
• Ethernet Terminals
• Supports 10/100 Base-T applications
• Compact Design Fits Easily in WLAN Access
• Plug-and-Play no configuration required
• Internal power supply
• Easy installation and maintenance
• Save up to 83% power with Green Technology
• complies to IEEE 802.3af/at PoE standard and is backward
• Chassis can be fixed to the wall

Specifications

• Pass Through Data Rates : 5-Port 10/100/1000 Mbps
• LED : Power, 10/100,1000, PoE Power over Ethernet Output
• Pin Assignment and Polarity: Endspan:1/2 (+), 3/6 (–) ;Optional Midspan 4/5(+),7/8(–)
• Output Power Voltage: 54-56 Vdc
• User Port Power: >16W /300ma or 30W/600ma
• Total Power: 65W
• Input Power AC Input Voltage: 100 to 240 Vac
• Requirements AC Input Current: 2A @ 100-240 Vac
• AC Frequency: 50 to 60 Hz
• Dimensions (W x D x H): 180 mm x 113 mm x 37mm
• Weight :0.8Kg
• Single packing weight： 1KG ，SIZE 200*150*50mm
• CTN SIZE:450*320*100 (20PCS) 10KG
• Indicators: System Indicator: AC Power (Green)
• User Indicator: Channel Power
• Connectors: Shielded RJ-45, EIA 568A and 568B
• Environmental Conditions :
• Operating Ambient Temperature: -10 to 45oC
• Reliability MTBF: 100,000 hrs. @25oC
• Warranty 1-year
• Regulatory IEEE 802.3at, IEEE 802.3af,Compliance RoHS Compliant , CE ,FCC Safety Approvals EN 60950:2006

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
