Part Number: SC-UPC-SF19
SC/UPC Optical Attenuator Female to Female Singlemode, Fixed Type
As optical passive devices,F-tone attenuators are mainly used in fiber optic to debug optical power performance & optical instrument calibration correction & fiber signal attenuation to ensure the optical power in a stable and desired level in the link without any changes on its original transmission wave.
| Fiber Connector | SC/UPC | Ferrule Type | Zirconia Ceramic |
|---|---|---|---|
| Connector Gender | Fixed Female to Female | Transfer Mode | Singlemode |
| Attenuation | 1~20dB | Operating Wavelength(nm) | 1260~1620(SM) |
| Attenuation Accuracy | ±0.5dB | Return Loss | ≥45dB |
| Polarization Dependent Loss | ≤0.2dB | Max Optical Input Power | 200mW |
| Humidity | 95%RH | Operating Temp Range | -40~80°C |
| Storage Temp Range | -40~85°C |
Highlights
- Precise attenuation values
- Low PDL & insertion loss
- Precisional reflection polishing
Accurate size armed with elegant dust cap, better ensure the handy installation and protection from out-service.
Shaped with metal material, our attenuators perfectly protect the core insert from external damage.
Delicate packaging, convenient for using and well-protected in transit to ensure no-damage delivery.
Optical attenuator is a passive device used to reduce the power level of an optical signal. It is generally used in single-mode long-haul applications to prevent optical overload at the receiver. Optical attenuator is widely used in CWDM&DWDM, CATV systems, data center networks, test equipment and other high power applications.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
