Silicon Carbide MPO Fiber Polishing Film SC3

Part Number: SC3-FM

MPO Fiber Polishing Film DSC3

Features:

1. The micro- or nano-scale green silicon carbide with good morphology is used as the abrasive material, which has good cutting force and strong wear resistance
2. Adhesive system adopts new polymer material, which has good water resistance and alcohol resistance;
3. Proprietary formulating technology ensures uniform dispersion of abrasive particles;
4. Stable product quality and small differences between batches;
5. Not only has the high grinding force characteristics of fixed abrasives such as grinding wheels, but also can achieve the polishing accuracy of free abrasives such as grinding fluid;
6. The product is suitable for dry polishing and also for polishing with water or oil as the grinding medium.

Specifications:

Mesh # 8000 # 6000 # 4000 # 3000 # 2000 # 1200 # 600
Particle size / um 1 2 3 5 9 15 30
Round Φ70mm, Φ110mm, Φ127mm (5inch), Φ203mm (8inch)
45m (150feet), 100m, 183m (600feet), 200m
Banded 1.6mm, 2.0mm, 2.5mm, 3.0mm, 3.2mm, 3.8mm, 5.0mm, 12.6mm, 25.4mm

Note: In addition to the above specifications, other specifications can be customized according to customer needs.

Application areas:

Suitable for high precision processing and mirror polishing of various materials, such as:
1. Grinding and polishing of plastic optical fiber;
2. Coarse grinding of ceramic optical fiber;
3. Fine grinding and polishing of floppy heads.

Application:

1. Optical fiber polishing; optical fiber polishing; optical fiber polishing; optical fiber end surface polishing; optical fiber end surface polishing; optical fiber end surface polishing; optical fiber jumper polishing; optical fiber jumper polishing; optical communications polishing; Optical fiber connector polishing;

2. FC grinding; SC grinding; ST grinding; LC grinding; MU grinding; MTRJ grinding; MPO grinding; FA grinding; PLC grinding; Pigtail grinding; Glass fiber grinding; Metal ferrule grinding; Glass capillary grinding;

3. Pigtail polishing; glass fiber polishing; metal ferrule polishing; glass capillary polishing; FC polishing; SC polishing; ST polishing; LC polishing; MU polishing; MTRJ polishing; MPO polishing; FA polishing; PLC polishing;

4. Pigtail grinding; glass fiber grinding; metal ferrule grinding; glass capillary grinding; Pigtail polishing; glass fiber polishing; metal ferrule polishing; glass capillary polishing; single-mode fiber; multimode fiber; vertex offset; fiber height; curvature Radius; extended life; good 3D parameters;

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
