Self-latching Connector SMPTE Hybrid Fiber Cable Socket Assembly EDW FXW with LC/FC/SC/ST Connector

Self-latching Connector SMPTE Hybrid Fiber Cable Socket Assembly EDW FXW with LC/FC/SC/ST Connector

View full details

Self-latching Connector SMPTE Hybrid Fiber Cable Socket Assembly EDW FXW with LC/FC/SC/ST Connector

Key attributes

Type Connector
Application Audio & Video
Gender Other

Other attributes

Place of Origin Cheng Du, China
Brand Name F-tone Networks
Model Number
EDW-SC
Contact Material
Copper
Housing Material Stainless Steel
IP Level IP67
Shape Round
Material Stainless Steel
MOQ 2pcs
Usage Video Equipment
Connector 3K 93C
Standard SMPTE304, 311M/ARIB/EBU
Packing Plastic Bag + Carton
Temperature Range -40 ~+85
Mechanism push-pull self-latching
Industry HDTV & Media

Packaging and delivery

Selling Units: Single item
Single package size:
10X10X5 cm
Single gross weight:
1.000 kg

Product descriptions from the supplier

Product Introduction

Details Images

Features：

  • Quick-connect plug-and -pull self-locking system with insertion loss ≤0.1dB
  • Two-way fiber, two-way power supply and two-pin signal core configuration
  • Stainless steel casing is suitable for various 20,000 times of insertion and removal, especially in harsh environments
  • It can withstand 1.5M water depth immersion after connection
  • Fiber core cleaning is simple and convenient
  • High and low temperature resistance, working temperature range -40℃ to 80℃
  • Optional pre-terminated F2 fiber ferrule, quick and easy on-site installation.
  • Comply with SMPTE, ARIB & EBU Standard

Applications：

  • DTV/HDTV Camera Systems
  • Graphics Transmission Systems
  • Outdoor or Indoor monitoring Systems
  • LAN Systems
  • Industrial Robotics

Keywords:

Lemo 3k 93c HDTV Broadcast & Camera SMPTE 304 SMPTE311M ARIB EBU G657A FUW Plug with PUW Socket EDW or FXW socket HD Camera optical
cable 3k 93C series Camera fiber assembly LEMO SMPTE304 Broadcasting camera cable photoelectric hybrid camera cable tactical fiber
cable for camera & video EDW/FXW with LC plug compatible Lemo connectors Straight plug push-pull self-latching fixed socket EDW

Connection Diagram

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
