Part Number: SM-SX-MU-FM
Simplex 9/125 Single-mode MU-UPC Pigtail
Fiber pigtail cables provide a fast way to make factory terminations in the field. Factory terminated pigtails can easily be fusion or mechanically spliced to an existing fiber line.
F-tone.COM provide wide degree flexibility on fiber pigtails, including single-mode, multimode and 10G 50/125um OM3 types, simplex fiber, 4 fibers, 6 fibers, 8 fibers, 12 fibers, 24 fibers, 48 fibers and so on. These fiber pigtails can be with fan-out kits and full compliant to Telcordia, EIA/TIA and IEC standards.
Features
- Low insertion loss and back reflection loss
- Good exchangeability
- Good Durability
- High temperature stability
- Compliant to IEC, TIA/EIA, NTT and JIS specifications
Applications
- FTTx, LAN, PON
- Optical CATV
- Local ring net
- Optical fiber communication system
- Optical fiber test equipment
- Optical fiber sensor
Specification
| Parameter | Specification |
| Connector | MU |
| Fiber | Simplex |
| Mode Type | Singlemode 9/125 |
| Polishing | UPC |
| Insert Loss | ≤ 0.2 dB |
| Return Loss | PC/UPC > 35dB APC > 60dB |
| Temperature Range | -40 ~ +55 ° C |
| Cable Diameter | 0.9mm /2.0mm /3.0mm (Price is same for the 3 diameters. You can specify your requirements in your order comments.) |
Custom Information
F-tone offers custom-made pigtails with a wide variety of options:
a. “Unjacketed” fiber pigtails usually installed inside ODF unit.
b. Multi-Strand fiber pigtails without a jacket are ideal for fusion splicing.
c. Multi-Strand fiber pigtails with fan-out are designed for patch panels or cable ducts where space-saving is required.
d. 2, 4, 6, 8, 12, 24 and 48 Strand fiber counts available.
Note :All pigtails can be customized in any fiber type, length, connectors and fiber counts for your requirement.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
