SMA905-SMA905 Duplex OM4 Fiber Patch Cable

SMA905-SMA905 Duplex OM4 Fiber Patch Cable

View full details

Part Number: SMA5-SMA5-DX-OM4-FM

SMA905-SMA905 Duplex OM4 Fiber Patch Cable

The SMA-905 fiber optic patch cord, also known as FTMA connector, was one of the First fiber optic interconnect system that gained industry wide acceptance.SMA905 fiber patch cords make use of threaded connections and is still widely used for military, industrial, medical and Surgical applications and laser systems because of their low cost multimode coupling. It features simple termination and Assembly, and is TIA and IEC compliant. SMA 905 multimode connectors are available with stainless alloy or stainless steel ferrules.

Connector Features

  • 1-4- 36 - UNS thread locking mechanism
  • 3.175 mm cylindrical drivepipe
  • Core diameter：0.126mm 0.23mm
  • The minimum bending radius:10D（D：optical fiber Core diameter）
  • Numerical Aperture：0.4-0.5na
  • Out-Track：2.0mm/3.0mm/2.5mm
  • Insertion loss：0.5db
  • Wavelength：650nm

Applications

  • Transmission with low loss, high transmission rate, high precision
  • Laser surgery
  • Photodynamic Therapy
  • Spectral measurement
  • Laser bonding
  • Illumination
  • Sensor

Make to Order

Connector Type Inner Hole Size Concentricity Roundness Core Material
Metal Ferrule Zirconia Ferrule 0.127~1.200mm ≤3.0μm ≤2.0μm stainless steel cupronickel

Notes:
1 The default ferrule of the connector is Metal Ferrule,please post a inquiry for Zirconia Ferrule. 2 The common size standard of Inner Hole is 127+3/-0μm,please kindly enquiry us for other size standards.

Special Customization Requirements for High Power SMA905-SMA905 Duplex OM4 Dia2.5mm Fiber Patch Cable

Connector Type Tailstock of Connector Bare fiber clamp Ferrule Inside Diameter Concentricity RoundnEss Core Material length
Metal Ferrule With groove Standard (Default) With 127-2000 um ≤5um ≤2um stainless steel 1m, 2m... custom
Without groove (Default)
Zirconia Ferrule Lengthen (custom) Without (Default) cupronickel

Sample Pictures


Custom OEM



Note:
F-tone is a professional manufacturer and supplier of fiber optic cables. Any customized service is offered here. If you have any special requirements of High Power SMA905 Fiber Patch Cable in accordance with the specification sheet above, please email us to [email protected] or call at +86-01-86-2786-1199.F-tone will try his best to work out a cost-effective solution for your special requirements.

Specifications

The numerical aperture of the Quartz fiber： 0.22-0.37
Fiber Diameter(mm) 0.2 0.3 0.4 0.5 0.6 0.65 0.8
Minimum Bending Radius 10D (D：optical fiber core diameter)
Fiber Cor(coating layer): 1：1.05 or 1：1.4
Numerical Aperture 0.21-0.37
Transmission(%/m0) Transmission(0.20-0.4um) 85-98
Visible Light(0.4-0.7um) 97-99
Near-Infrared(0.76-1.6um) 90-99
Heliun-Neon(0.6328um) 99
YAG(1.06um) 98
Argon(0.5145um) 98
Transmission Power >130w(fibre [email protected])



This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
