Part Number: SOR-860C4
4 Channels CATV optical receiver with original module Standard Outdoor Single mode
CATV Receiver is bidirectional design, HFC transmitting products. Modulization, plug-in design, collocate according to customers requirements. Add return path can update as bidirectional Optical Workstation. Use PIN diode and receiving module, GaAs amplifier module(front-positioned) give super low noise and low Optic power receiving;RF signal amplify, impulse power, one way individual output or two output. Maximum Output level is 114dBμV(0 dBm input power), every output can be used as reverse path.
Key Features
- Use PIN diode or optical receiving module
- Receiving Optical Wavelength:1290mn~1600nm
- 1000MHz design, (750/862MHz)
- Plug-in bidirectional filter:30/47MHz~42/54MHz~65/87MHz Optional
- Plug-in Circuit improve non-linear distortion
- 1 way coupler output or 2 splitter output
- Ruturn path can use at any time and update Network.(optionVRT-200X/P Return transmitter)
- With optical power monitor
- Power supply:60V/AC and 220V/AC optional
- SMPS and with wide range of voltage
Specification
| Electonic Parameter: | |
| Frequency range | 45~750/862MHz |
| Flatness in band | ± 0.75dB |
| Return loss | ≥ 16dB(45~750MHz) |
| ≥ 14dB(750~862MHz) | |
| Nominal output level | 112dBμV |
| Max. Output Level | 112dBμV0dBm |
| CNR | ≥ 51dB |
| C/CSO | ≥ 60dB |
| C/CTB | ≥ 65dB |
| Gain Adjustment Range | 0~20dB |
| Slope Adjustment Range | 0~12dB |
| Test Level | -20dB±1dB |
| Amplify Gain | 18dB~28dB Optional |
| Frequency Range | 5~200MHz |
| Reverse OT. Flatness | ± 0.75dB |
| Output Impedance | 75Ω |
| Connector Type | F-connector or 5/824 connector |
| Power Supply | 60V /AC or 220V /DC48V |
| Current | 10A (60V/AC Power Supply) |
| Power Consumption | 30W Max |
| Optical Parameter: | |
| IN Optical Wavelength | 1290nm~1600nm |
| Return loss | 45dB |
| Current | 0.85A /W(1310nm) |
| Optical Power Range | -4 ~+2dBm |
| Max. Input Power | 2mW(+3dBm) |
| Fibre Type | SM9 /125μm) |
| Connector Type | FC /APC or SC /APC |
| Output Power | ≥ -3dBm |
| Optical Wavelength | 1310nm or 1550nm |
| Environment Parameter: | |
| Storage Temperature | -40~+70 temp |
| Storage Humidity | Rh80%,Non-acidity |
| Operating Temperature | -25~+55 temp |
| Operating Humidity | 40~80%,Non-acidity |
| Size | L300×B210×H130mm |
Applications
CATV Networks
FTTH networks
receiver-ONU Side
Transmission of video and sound through Hybrid Fiber Coaxial (HFC) networks
Ordering Information
| Part No. | Channels | Bandwidth | Power | RX | wavelength(nm) | configuration |
|---|---|---|---|---|---|---|
| SOR-860C4 | 4 | 860MHz | -4 ~+2dBm | PIN | 1310/1550 | Inner Signal Module (Original) |
| SOR-860C4-FM | 4 | 860MHz | -4 ~+2dBm | PIN | 1310/1550 | Inner Signal Module |
| SOR-860C2 | 2 | 860MHz | -4 ~+2dBm | PIN | 1310/1550 | Inner Signal Module (Original) |
| SOR-860C2-FM | 2 | 860MHz | -4 ~+2dBm | PIN | 1310/1550 | Inner Signal Module |
Notes: F-tone provide customized solutions for all needs and specifications,like Part Number,S/N,Vendor Name,Label,etc. We create a made-to-order CATV receiver just for you. Please email us at [email protected] for your additional customized requirements.
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
