Desktop Variable Optical Attenuator ST-3301A(0～60dB)

Desktop Variable Optical Attenuator ST-3301A(0～60dB)

View full details

Part Number: ST-3301A

Desktop Variable Optical Attenuator ST-3301A (0～60dB)

ST-3301A variable optical attenuator is a general instrument designed based on the requiring of fiberoptic communication equipment’s design and engineering application.

Key Features

Specification

  • Lower power consumption
  • Small volume
  • Light weight
  • Higher attenuation accuracy
  • Wide attenuation range

Applications

  • Testing and evaluating fiber optic transmission systems, subsystems and components
  • Fiber optic computer network, fiber optic CATV network
  • Testing optical sources and optical transmitter/receiver directly
  • Design of variable optical communication systems
Wavelength 1310/1550/1625/1650
Insertionloss <1.5dB
Returnloss >60dB(APC)
>50dB(PC)
Standardopticalconnector FC
Attenuationrange 0to65dB
Maximuminputpower <500mW
Display LCD
Resolution 0.01dB
Accuracy ≤±0.1db
PDL ≤0.25dB
Repeatability 0.2dB
PCinterface RS-232
Operatingtemperaturerange 0~50℃
Operatinghumidityrange ≤85%


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
