Sunma ST-3302A Handheld OTDR Single-Mode 1310/1550nm, 32/32dB

Part Number: ST-3302A

Sunma ST-3302A Handheld OTDR Single-Mode 1310/1550nm, 32/32dB

Description

ST-3302A handheld OTDR is a high performance, cost-effective optical network analysis test equipment, with the features of light weight, elegant appearance, small size and easy to operate. 3.5 Inch TFT-LCD can meet the needs of high luminance environment. ST-3302A OTDR provides three power saving modes, closing screen, sleep mode and power off, to ensure the equipment having longer working time.

Features

• Configuration 650 nm visible light source
• Quick start :< 5 seconds
• Unique hotkey desigh: Key operation integrated hotkey function , fast positioning and analysis of events
• USB/RS-232 data interface
• 1000 test records storage
• Optimization design of power supply：Built-in NiMH rechargeable battery charge once can support 8 hours measurement
• Multiple languages: CN/EN/DE/FR/RU/ES/PT/KR/VN
• Dust-shock proof (2m drop test)
• CE, FCC, FDA certificates

Live Optical Signal Check Function

To have live optical signal check function, before a test pulse. First check test whether any of the optical fiber live communication optical signals and display the results.It can effectively protect test instrument and communications equipment.

Complete software support

• Single page single tracing line or single page more tracing line can choose the print mode；
• Batch change and batch print function；
• Waveform difference contrast function；
• Can be in the same window open multiple tracing line at the same time, the differences between the tracing line in the same window display and more easily compare such as optical fiber aging caused by the reasons changing parameters;
• Bidirectional testing function.

Standard Package Includes:

Instrument, FC/PC connector, NiMH battery, TraceManager software CD, Data cable (USB/RS-232), AC adaptor, Soft carrying case, Warranty card, CE certificate, Certificate of calibration, Quick reference guide.

This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
