Part Number: SUNMA-Manu-OAS
Manual Align Optical Waveguide Alignment Machine for Fiber Chip Coupling Manufacuturing, Optical Coupling system of Optical Chip and Fiber Array, Optical Fiber Align System & optical waveguide alignment and packaging
Low-cost, Compact, High Precision and Maneuverable Manual-Alignment Machine for PLC Splitter Manufacuring and Alignment of PLC Fiber Chip and Fiber Array Pigtailing
The Sunma instrument company develops a new generation of manual and auto aligner for planar lightwavecircuit(PLC)manufacturing. This product line features cost effective, high precision motion control capability with a compact mechanical design. Optical Alignment Machine
High quality components are used to assemble the system to guarantee high precision and repetitive motion applications.OEM customized manual, semi-auto and fully automatic system according to customer’s applications.
We provide 2-day Free training, Installation& Calibration, all for Free.
Features:
- High Stability Stainless Steel Ultra-Precision linear stage
- High Repeatability Stainless Steel fixtures and jigs
- High resolution motion platform and micrometer for high precision and repeatability waveguide alignment
- Compact and highly maneuverable design
- Modular design, seamless upgrade to piezo-electric and motor-driven semi-auto alignment system
- Customized Workflow Software Control with different algorithm for auto fiber to chip/PIC coupling alignment
Applications:
- Silicon waveguide alignment/coupling
- 1xN Splitter
- 2xN splitter
- Arrayed waveguide grating
- Collimator
- Special/customized optical fiber and other related optical waveguide alignment
System confguration:
Specifications:
| Translation（X-Y-Z axis） | |
|---|---|
| Component | Sunma 562 ULTRAlignTM Precision Multi-Axis Positioning System |
| Travel Range（mm） | XYZ: 13mm (X, Z optional 25mm) |
| Actuator Resolution（μm） | SM-13 (0.5); DM-13 (0.05) |
| Load Capacity（N） | 156 |
| Materials | All Stainless Steel |
| Rotation（PitchθX-YawθY-RollθZaxis） | |
| Component | NP-YP1 (Pitch-Yaw); NP-R1 (Roll) |
| Travel Range（mm） | θX:6mm, θY:6mm, θZ:12mm (±3°) |
| Resolution（μm） | NP-YP1 (0.01°), NP-R1 (0.0004°) |
| Materials | Stainless Steel/Aluminium |
| Tooling | |
| （Patent Pending）Universal Fiber Array Holder × 2 | |
| （Patent Pending）Universal 1×N Splitter Holder（1×2 to 1×64）× 1 | |
| Vision | |
| Camera Type | CCD×3 |
| Lighting | LED Bar Light（Top view、Side view） |
| Motion | 100mm（according to request） 6 or 13mm manual XY stage |
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
