MEMS 1x3 Optical Switch 1260-1650nm SM Fiber TTL+UART control

MEMS 1x3 Optical Switch 1260-1650nm SM Fiber TTL+UART control

View full details

Part Number: SWITCH-1X3MEMS

MEMS 1×N Optical Switch 1260-1650nm, SM Fiber, TTL+UART control

1． PRODUCT OVERVIEW

OSW-1×N optical switch Hereinafter referred to as MEMS optical switch , a multi-channel optical path switch modularization product which is researched by F-tone. MEMS optical switch based on electrostatic drivin g and vertical micro technology is presented. Due to its advantages such as small in size, quickly and stable performance, it is mainly used in optical communication and test system. The optical path schemes as follows:

2. TYPICAL APPLICATIONS

● Multi-optical channel monitoring in optical transmission system
● LAN multi optical source/ detector auto switch, optical sensing multi -point
dynamic monitoring system
● It is mainly used for Optical fiber, optical device, network and open
country project automatic system test
● Installation and debugging of optical device

3. FEATURES

●Frequency switching speed
●Proven MEMS durability and reliability
●Small and exquisite volume
●TTL Control interface
●Modularize design
●Low Insertion Loss

4. Specification


This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
