Part Number: XFP-8G85-3M
8GBASE XFP 850nm 300m MMF SR Transceiver
F-tone’s Small Form Factor 8.5Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification1. They comply with 8.5-Gigabit Ethernet 8GBASE-ER/EW per IEEE 802.3ae. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA. The transceiver is RoHS compliant and leads free per Directive 2002/95/EC3
Key Features
- Compliance to Fiber Channel 800-M5-SN-l,800-M5E-SN-l, 800-M6-SN-l at 8.5Gbit/s
- Laser Class 1M compliant
- Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
- Compatible with RoHS
- Vertical Cavity Surface Emitting Laser at 850nm(VCSEL)
- Average Output Power:-7.3~-1dBm
- Receiver Sensitivity:-11.1dBm
- Transmission distance up to 300m with OM3 MMF; 82m with OM2 MMF; 33m with OM1 MMF
- Fully compliant to XFP MSA Rev.4.5
Applications
- 8.5G Fiber Channel Links
- Other optical links
Ordering Information
| Part No. | Data Rate (Gbps) | Wavelength (nm) | TX Power (dBm) | Re Sens. (dBm) | Transmission Distance | Fiber Type | Connector Type | Temp. Range | Digital Diagnostics |
|---|---|---|---|---|---|---|---|---|---|
| XFP-8G85-3M | 8.5G | 850 | -7.3~-1 | ﹤-11.1 | 300m | MMF | LC | Com./Ex./Ind. | Yes |
| XFP-8G31-10 | 8.5G | 1310 | -5~0 | ﹤-11.1 | 10km | SMF | LC | 0~70℃ | Yes |
| XFP-8G55-40 | 8.5G | 1550 | 40km | SMF | LC | 0~70℃ | Yes | ||
| XFP-8G55-80 | 8.5G | 1550 | 80km | SMF | LC | 0~70℃ | Yes |
Packaging
- Antistatic bag
- Packed on pallets in a box(Default Customer Options)
- Specific Labels as Request
- Seperate white Box for each transceiver
OEM and ODM
Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, F-tone provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence for F-tone in the world.
- OEM/ODM order is available
- We can supply XFP-8G85-3M according to your requirements, and design XFP-8G85-3M label and packaging for your company. We welcome any inquiry for customized 8G XFP optical transceiver.
Order Procedure
Please contact us with any special requirements you may have, we can help you create a custom solution to meet almost any application. Our engineer will review the project and provide a quotation within 1-2 business days.
a. Email ([email protected]) us a rough sketch to a detailed drawing.
b. Our engineer will review the project and provide a quotation within 24 hours.
c. We can arrange production as low as 1 piece and as high as 1,000 pieces in 1~4 business days once an order is placed.
Shipment
International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
Save Cost By Buying 8G XFP From Original Manufacturer F-tone Directly.
F-tone is an professional manufacturer & supplier of 8G XFP transceivers. All of our 8G XFP transceivers are tested in-house prior to shipping to guarantee that they will arrive in perfect physical and working condition. We guarantee 8G XFP transceivers to work in your system and all of our 8G XFP transceivers come with a lifetime advance replacement warranty. If you have questions about 8G XFP optics, please feel free to contact us at [email protected].
This product belongs to F-tone Networks' optical components product line. For detailed specifications, please contact our sales team. Thank you!
Important Notice:
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
